Dds Signal Generator Ad9850 0~55mhz For Ham Ssb6.1 Transceiver Vfo Ssb L2ke

US $25.84

Shenzhen ,Guangdong, China
Aug 10th

Open on mobile:
QR code

Store CategoriesStore Categories Electronic Components&toolMagnet Welding toolThermal Paste Solder Paste Soldering Wire Spot Welders Socket Connector Electronic toolsEngraver Pen Repair Watch tool Rain Gauge LED LightLED Lamp Base LED String LED Light Bulb LED DIP Light LED SMD Light Diodes/Rectifiers Capacitor/Resistor Switch other ICsother Arduino ModuleArduinoNodemcu ESP series WEMOS D1 Mega Motor Drive Module other Module & Development BoardAmplifier Signal Generator/Transmitter USB Module Development Board Power Module?DC-DC and DC-AC? Clock Module Bluetooth Module Breadboard Digital Thermostat Controller LCD/LED/TFT Disply Logic board WIFI/Wireless Module Server Module Relay Sensor Voice Module Voltage Regulator other MeterCurrent Voltage meter Tester Multimeter AnalysisInstruments other Raspberry/Orange PiOrange Pi Expansion Board Raspberry Pi other 3D Printers & AccessoriesBearing Jaw Shaft Pump other Flight Control APMDrone accessories RC Drone other Auto Parts & AccessoriesGrille Logo Car Sun visor Car Lights Car DVRs GPS & Accessories Car Electronics Parts/Accessor Car Audio & Monitor Car Alarm & Security Diagnostic Scan Tool Car Repair & Maintenance Electric Scooters Car Cradles & Mounts Motor other Fashion/BeautyBeautyBeauty tools Makeup brush Earring/Quartz watches Jewelry Baby Products other Fashion/HealthMaternal and Child Health Healthy Medical ProductFitness Smart wristband Oral health Blood Pressure Monitor Otoscope Massager Humidity Thermometer other Smart ElecyronicsTracker/Anti Lost Device Alarm System Electric Charging tool Solar Power Cables|Connectors|PCB|kitsDupont Wire Adapter USB Socket Converter USB Converter Cable DIY Kit HDMI Computers,TV Home Audio ElectrKeyboard Mouse Heatsink Cooling fan Screen/Media player Wireless Receiver Devices TV Box NetworkingAdapters&Antennas Games Accessories Consumer ElectronicsCamera Headset Power Bank Microphone Speaker Radio Smart Switch PIR Sensor Memory Fingerprint Lock Smart Watch Clock Electronic scale Humidifier Steam brush Projector Flashlight other Motorcycles & AccessoriesBicycle Motorcycle other ToysMagic Cube Playing Card Mask Gyro/Hand Spinner RC Cars Other other BatteryLithium battery PCB board lithium/Li-ion battery Battery Case other Sports & OutdoorFishing&Hunting SOS kit Camping light other Other Product View Detail #1 0~55MHz DDS (RED) Description: This is a 0~55MHz DDS Signal Generator. It is based on AD9850 chip and is very easy to operate. Supports 0~55MHz continual adjust at 1Hz step. Input 12V (Seller's Note: We are also providing a simplified version, with input 8~9V) With direct digital input frequency With audio volume potentiometer With amp. gain potentiometer With AGC potentiometer S-LED display Standing Wave-LED display Keys & Connection interfaces: ENC: encoder switch MEM: switch for memory mode VFO: Transfer from VFO A to VFO B, or from VFO B to VFO A. SSB: Working mode change: circulate from USB, LSB, AM, CW, and on and on... RIT: fine tuning to receiving frequency CAL: set functions KB-1 and KB-2 have common shared pin, but is not GND. How to operate: Press CAL, power on, then we enter setting screen. Let go/release CAL. A: ENABLE 6XREFCLE: setting chip clock mode, adjust frequency encoding setting. AD9851 set to 6-multiply frequency, AD9850 set to 1multiply frequency. Press CAL then quickly release to enter next step B. B: DDS-SYSTEM-CLK: Chip working frequency setting. Use encoder switch to adjust value. Operate in accordance with STEP key. AD9851 set at oscillator 6-multiply channel, AD9850 set at actual output of oscillator. Press CAL then quickly release to enter step C. C: MIN_RX_DDS_FREQSetting minimum working frequency. Use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step D. D: MAX_RX_DDS_FREQSetting maximum working frequency. Use encoder switch to adjust value and in accordance with STEP key. (Smaller than 60MHz would be OK ). Press CAL then quickly release to enter step E. E: SSB_OFFSETFine tuning for SSB working mode. Use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step F. F: CW_OFFSETFine tuning for CW working mode. Use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step G. G: OFFSET_FREQSetting of offset Frequency. e.g, set to 9MHz or 10.7MHz, use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step H. H: MULTIPLIER: multiply setting for frequency. Should be set as 1, press CAL then quickly release to enter step I: I: Screen displayes word "SAVE", automatically save the above setting, and returns to normal working. Notes: 1. DDS SYSTEM CLK: can use frequency tester to get 30MHz oscillator, multiply the tested value at 6, then put the multiplied value here. If using AD9851, make initial setting at 180000000. 2. OFFSET FREQ: can be set as + or - . Rotate encoder switch to change value, press STEP key, then rotate encoder switch to adjust step. Minimum working frequency plus (+) offset frequency should be high than 0 (zero). Frequency display: RX = MULTIPLIER x (RX_DDS_FREQ + OFFSET_FREQ) TX = MULTIPLIER x (RX_DDS_FREQ + OFFSET_FREQ + TX_OFFSET_FREQ) The frequency programmed into the DDS, is calculated as shown below. RX = ABS(RX_DDS_FREQ) TX = ABS(RX_DDS_FREQ + TX_OFFSET_FREQ) RX_DDS_FREQ, MIN_RX_DDS_FREQ, MAX_RX_DDS_FREQ, TX_OFFSET_FREQ & OFFSET_FREQ Examples: 1. DDS output range 30~40MHz: MIN_RX_DDS_FREQ MAX_RX_DDS_FREQ OFFSET_FREQ RX Frequency display range. 30 MHZ 40 MHz 100 MHz = 130 MHz to 140 MHz. \ Note 1 30 MHZ 40 MHz -10 MHz = 20 MHz to 30 MHz. / -40 MHZ -30 MHz 170 MHz = 140 MHz to 130 MHz. \ Note 2 -40 MHZ -30 MHz 60 MHz = 30 MHz to 20 MHz. / 2. setting FT180A with DDS: ENABLE RPT NO X6 RECLK X6 DDS SYSTEM CLK 180M MAX DDS FREQ 65M MIN RX DDS FREQ 10.701M (Offset frequency + RIT frequency) MAX RX DDS FREQ 60M TX OFFSET FREQ 0 MAX RIT OFFSET 1K (RIT frequency) OFFSET FREQ 10.700M (Offset frequency) MULTIPLIER 1 Package Contents 1x DDS Signal Generator AD9850 0~55MHz for HAM Radio SSB6.1 Transceiver VFO SSB #2 0~55MHz DDS (Blue) Description: This is a 0~55MHz DDS Signal Generator. It is based on AD9850 chip and is very easy to operate. Supports 0~55MHz continual adjust at 1Hz step. This generator has 78L05 voltage regulate. Input current at 200MA, input voltage 8-9V would be the ideal voltage. Input voltage of 12V can only be used for short time testing, otherwise will cause heat to board. 5p/6p connect to encoder as per photo. 7p of the middle connects to digital matrix input. 14p (8V GND) is 8V power supply from main board. If powered by main board, DDS does not need independent power supply. 1~6 correspond to 6 frequency bands: (3.87 91418 or 2127 or 29) ISB, USB, CW are the three mode choices. DT is signal from main board. Keys & Connection interfaces: ENC: encoder switch MEM: switch for memory mode VFO: Transfer from VFO A to VFO B, or from VFO B to VFO A. SSB: Working mode change: circulate from USB, LSB, AM, CW, and on and on... RIT: fine tuning to receiving frequency CAL: set functions KB-1 and KB-2 have common shared pin, but is not GND. How to operate: Press CAL, power on, then we enter setting screen. Let go/release CAL. A: ENABLE 6XREFCLE: setting chip clock mode, adjust frequency encoding setting. AD9851 set to 6-multiply frequency, AD9850 set to 1multiply frequency. Press CAL then quickly release to enter next step B. B: DDS-SYSTEM-CLK: Chip working frequency setting. Use encoder switch to adjust value. Operate in accordance with STEP key. AD9851 set at oscillator 6-multiply channel, AD9850 set at actual output of oscillator. Press CAL then quickly release to enter step C. C: MIN_RX_DDS_FREQSetting minimum working frequency. Use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step D. D: MAX_RX_DDS_FREQSetting maximum working frequency. Use encoder switch to adjust value and in accordance with STEP key. (Smaller than 60MHz would be OK ). Press CAL then quickly release to enter step E. E: SSB_OFFSETFine tuning for SSB working mode. Use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step F. F: CW_OFFSETFine tuning for CW working mode. Use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step G. G: OFFSET_FREQSetting of offset Frequency. e.g, set to 9MHz or 10.7MHz, use encoder switch to adjust value and in accordance with STEP key. Press CAL then quickly release to enter step H. H: MULTIPLIER: multiply setting for frequency. Should be set as 1, press CAL then quickly release to enter step I: I: Screen displayes word "SAVE", automatically save the above setting, and returns to normal working. Notes: 1. DDS SYSTEM CLK: can use frequency tester to get 30MHz oscillator, multiply the tested value at 6, then put the multiplied value here. If using AD9851, make initial setting at 180000000. 2. OFFSET FREQ: can be set as + or - . Rotate encoder switch to change value, press STEP key, then rotate encoder switch to adjust step. Minimum working frequency plus (+) offset frequency should be high than 0 (zero). Frequency display: RX = MULTIPLIER x (RX_DDS_FREQ + OFFSET_FREQ) TX = MULTIPLIER x (RX_DDS_FREQ OFFSET_FREQ + TX_OFFSET_FREQ) The frequency programmed into the DDS, is calculated as shown below. RX = ABS(RX_DDS_FREQ) TX = ABS(RX_DDS_FREQ + TX_OFFSET_FREQ) RX_DDS_FREQ, MIN_RX_DDS_FREQ, MAX_RX_DDS_FREQ, TX_OFFSET_FREQ & OFFSET_FREQ Examples: 1. DDS output range 30~40MHz: MIN_RX_DDS_FREQ MAX_RX_DDS_FREQ OFFSET_FREQ RX Frequency display range. 30 MHZ 40 MHz 100 MHz = 130 MHz to 140 MHz. \ Note 1 30 MHZ 40 MHz -10 MHz = 20 MHz to 30 MHz. / -40 MHZ -30 MHz 170 MHz = 140 MHz to 130 MHz. \ Note 2 -40 MHZ -30 MHz 60 MHz = 30 MHz to 20 MHz. / 2. setting FT180A with DDS: ENABLE RPT NO X6 RECLK X6 DDS SYSTEM CLK 180M MAX DDS FREQ 65M MIN RX DDS FREQ 10.701M (Offset frequency + RIT frequency MAX RX DDS FREQ 60M TX OFFSET FREQ 0 MAX RIT OFFSET 1K (RIT frequency) OFFSET FREQ 10.700M (Offset frequency) MULTIPLIER 1 Package content 1 x AD9850 6 Bands 0~55MHz DDS Signal Generator Digital HAM Radio RIT VFO SSB Feedback Payment Shipment About us Feedback We appreciate positive feedback . we always try our best to service our customers . so if you have ant question ,PLEASE DON’T HESITATE TO TELL US, we are always here to offer help . Payment We prefer PayPal .For purchasing multiple items , please contact us for a combined invoice . generally we would like to receive payment thin 48 hours if . Shipment We provide airmail service with good package . The items will be shipped within the nest 2 business days after we received the payment . when you buy multiple items ,your shipping cost will be combined with discount . SHIPPING TIME (weekends/holidays excluded) Country Name Shipping Time Country Name Shipping Time USA/Canada 10 -15d Spanish/Portugue 10-25d East/South Asia 10 -15d France/West Asia 10-25d United Kingdom 10 -20d Italy 10-30d Australia/New Zealand 10 -15d West Asia/Middle East 15-25d Most Country of West/North Europe 10-20d South America and Africa 15-30d East /Middle Europe/Russia 10-25d About us NEW, GOOD QUALITY, ORIGINAL PACKAGE LARGE STORE AND THE LOWEST PRICE NO-QUESTION-REFUND, FOR LARGE QUANTITY ,OFFER BETTER PRICE,ORIGINAL PACKING(TAPE REEL/TUBE/TRAY We specialize in electronic components . ICs, Capacitors, Diodes, Resistors, LEDs, Transistors, and so on. Especially in Hard To Find Parts . we only sell NEW , ORIGINAL parts . please buy with confidence .We offer NO-QUESTION-REFUND go to my store
