Dds Sweep Function Waveform Signal Generator 5mhz 110-220v 2channels 100msa/s

US $218.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

ATF05C Support 110-220V power supply. This DDS function generator uses Direct Digital Synthesis (DDS) technology. Its outstanding performance and system features make this function generator a perfect solution for your testing requirement. The simplified and optimized design of the front panel and dual-language (English/Chinese) LCD display interface make your testing much easier for operation and observation. Additionally, the extendable optional functions can also improve your system characteristics. Technical characteristics and system features: l High-accurate Frequency: up to the 10-5 order of magnitude l High Frequency Resolution: full-range resolution is 40 mHz l No Range Limitation: no frequency level switch, frequency set directly by digit keypad l No Frequency Transition: momentarily switch to the stable value on phase and amplitude without transition and distortion l Precise Output Waveform: output waveform is synthesized by the preset function calculation values, very accurate and less distortion l Multiple Waveforms: output 32 kinds of the pre-stored waveforms l Pulse Characteristics: set accurate pulse duty cycle l Output Characteristics: two independent output channel, precisely set the phase of the two channel l Frequency Sweep: frequency sweep function, free to set the start and stop points l Amplitude Sweep: amplitude sweep function, free to set the start and stop points l Frequency Modulation: output FM signals l Shift Keying Characteristics: output FSK, ASK, and PSK signals l Burst Characteristics: output pulse waveform with burst count l Store Characteristics: store 40 sets of the user parameters and recall l Counter Characteristics: count the frequency, period, amplitude RMS value or peak-to-peak value l Operation Mode: key operation for all functions, English/Chinese menu selectable, parameters settings by numeric keypad or rotary dial l High Reliability: use VLSI components and surface mount technology l Protection: over voltage protection, over current protection, output short circuit protection, reverse voltage protection Output Characteristics of Channel A Waveform Characteristics Waveform type: 32 waveforms including: Sine, Square, Triangle, Ramp etc. Waveform length: 1024 points Sample rate: 100MSa/s Waveform amplitude resolution: 8bits Sinusoidal harmonic rejection: >=40dBc (<1MHz), >=35dBc (1MHz~20MHz) Sine wave total distortion:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	ATF05C
Country/Region of Manufacture	China
MPN	ATF05C
Country of Manufacture	China
