Dek 265 Infinity Smt Screen Printer

US $25,000.00

Wilsonville, Oregon, United States
Feb 24th

Open on mobile:
QR code

Description: Screen Frames Specification: Type External Standard DEK (29? x 29?) Image Position Center, Front, Custom Motorized Stencil Positioning Board Handling Specification: Minimum Size 40 x 50mm Maximum Size 510 x 508mm (620 x 508mm)* Thickness 0.2 - 6mm Warpage Up to 8mm including PCB thickness. Underside Component Clearance Programmable 3 - 42mm . Transport Conveyors Programmable motorized Transport Direction Left to Right Right to Left Left to Left Right to Right. Board Location Patented Over the Top Clamps Edge clamping* Vacuum* Foil-less Clamps with Vacuum* Registration Fully Automatic Vision. Print Modes ProFlow: Print Print Print Flood Flood Print Adhesive. Vision System Cognex 8100 Vision System On-The-Fly Vision Mode. Environmental Control Temperature Control Unit (TCU): Temperature and Humidity Control Unit (ECU): Controls the temperature and humidity of the printing area. Power Supply 100, 110, 120, 200, 210, 210, 220, 230, 240 volt Single Phase 50/60Hz Current: 110V - 16 Amps 120V - 15 Amps 200 - 220V - 8 Amps 230 - 240V - 7 Amps Air Supply Air to ISO 8573.1 standard quality class 2.3.3 Pressure 5 -8 bar at 5 Litres/min Approx Weight 900kg Approx Dimensions 51.7? x 52.1? x 62.6?

“Used / working condition. Machine was a part of a working SMT Line that has been recently taken off-line. The item may have some signs of cosmetic wear. Contact us to view this equipment prior to sale.”
