Delta 1.5kw Ac Servo Drive & Motor Asd-b2-1521-b+ecma-e21315ss With Cable

US $1,391.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Delta 1.5kw AC Servo Drive & Motor ASD-B2-1521-B + ECMA-E21315SS with Cable New Free shipping Features *High-resolution encoder with 17-bit (160,000 p/rev) is equipped as a standard feature which satisfies the application needs of high precision positioning control and stable rotation at low speed. *Satisfy High Precision Positioning Requirements *Offer Easy-To-Install Solution for Simple Start-Up *Reduce Maintenance and Wiring Cost for Versatile Operation Specifications Model: ASDA-B2 Series 100W 200W 400W 750W 1KW 1.5KW 2KW 3KW 01 02 04 07 10 15 20 30 Power Supply Phase / Voltage Three-phase: 170 ~ 255VAC, 50/60Hz ±5% Single-phase: 200 ~ 255VAC, 50/60Hz ±5% Three-phase: 170 ~ 255VAC, 50/60Hz ±5% Continuous Output Current 0.9 Arms 1.55 Arms 2.6 Arms 5.1 Arms 7.3 Arms 8.3 Arms 13.4 Arms 19.4 Arms Cooling System Natural Air Circulation Fan Cooling Encoder Resolution / Feedback Resolution 17-bit (160000 p/rev) Control of Main Circuit SVPWM Control Tuning Modes Auto / Manual Dynamic Brake - Built-in Speed Control Mode Analog Input Command Voltage Range 0 ~ ±10 VDC Input Resistance 10K? Time Constant 2.2?s Speed Control Range Torque Control Mode Analog Input Command Voltage Range 0 ~ ±10 VDC Input Resistance 10K? Time Constant 2.2?s Communication Interface RS-232/RS-485 Environment Altitude Altitude 1000m or lower above sea level Atmospheric pressure 86kPa to 106kPa Operating Temperature 0°Cto 55°C(32°F to 131°F) (If operating temperature is above specified range, forced cooling will be required) Storage Temperature -20°Cto 65°C Humidity 0 to 90% (non-condensing) IP Rating IP20 Power System TN System Standards/Requirement IEC/EN 61800-5-1, UL 508C Servo Drive and Servo Motor Combinations Power Servo Drive Servo Motor 100W ASD-B2-0121-B ECMA-C20401_S(S=8mm) 200W ASD-B2-0221-B ECMA-C20602_S(S=14mm) 400W ASD-B2-0421-B ECMA-C20604_S (S=14mm) ECMA-CM0604_S (S=14mm) ECMA-C20804_7 (7=14mm) ECMA-E21305_S (S=22mm) ECMA-G21303_S (S=22mm) 750W ASD-B2-0721-B ECMA-C20807_S (S=19mm) ECMA-C20907_S (S=16mm) ECMA-G21306_S (S=22mm) ECMA-GM1306_S (S=22mm) 1000W ASD-B2-1021-B ECMA-C21010_S (S=22mm) ECMA-C20910_S (S=16mm) ECMA-E21310_S (S=22mm) ECMA-G21309_S (S=22mm) ECMA-GM1309_S (S=22mm) 1500W ASD-B2-1521-B ECMA-E21315_S (S=22mm) 2000W ASD-B2-2023-B ECMA-C21020_S (S=22mm) ECMA-E21320_S (S=22mm) ECMA-E21820_S (S=35mm) 3000W ASD-B2-3023-B ECMA-E21830_S (S=35mm) ECMA-F21830_S (S=35mm) Applications Transportation Machine, Cutting Machine, Lathe and Milling Machines Other hot items of this B2 series for above applications: ASD-B2-0221-B Delta AC Servo Drive B2 Series ASD-B2-0221-B 220V 1/3-phase 200W New ASD-B2-0421-B Delta AC Servo Drive B2 Series ASD-B2-0421-B 220V 1/3-phase 400W New ASD-B2-1021-B Delta AC Servo Drive B2 Series ASD-B2-1021-B 220V 1/3-phase 1000W 1kw New ASD-B2-1521-B Delta AC Servo Drive B2 Series ASD-B2-1521-B 220V 1/3-phase 1500W 1.5kw New ECMA-E21315SS Features *High-resolution encoder with 17-bit (160,000 p/rev) is equipped as a standard feature which satisfies the application needs of high precision positioning control and stable rotation at low speed. *Satisfy High Precision Positioning Requirements *Offer Easy-To-Install Solution for Simple Start-Up *Reduce Maintenance and Wiring Cost for Versatile Operation Specifications Model: ECMA Series C204 C206 C208 C209 C210 01 02 04 04 07 07 10 10 20 Rated output power (kW) 0.1 0.2 0.4 0.4 0.75 0.75 1.0 1.0 2.0 Rated torque (N-m) 0.32 0.64 1.27 1.27 2.39 2.38 3.18 3.18 6.37 Maximum torque (N-m) 0.96 1.92 3.82 3.82 7.16 7.14 8.78 9.54 19.11 Rated speed (r/min) 3000 Maximum speed (r/min) 5000 3000 5000 Rated current (A) 0.90 1.55 2.60 2.60 5.10 3.66 4.25 7.30 12.05 Maximum current (A) 2.70 4.65 7.8 7.74 15.3 11 12.37 21.9 36.15 Power rating (kW/s) (without brake) 27.7 22.4 57.6 22.1 48.4 29.6 38.6 38.1 90.6 Rotor moment of inertia (x 10-4kg.m2) (without brake) 0.037 0.177 0.277 0.68 1.13 1.93 2.62 2.65 4.45 Mechanical time constant (ms) (without brake) 0.75 0.80 0.53 0.73 0.62 1.72 1.20 0.74 0.61 Torque constant-KT (N-m/A) 0.36 0.41 0.49 0.49 0.47 0.65 0.75 0.43 0.53 Voltage constant-KE (mV/(r/min)) 13.6 16.0 17.4 18.5 17.2 27.5 24.2 16.8 19.2 Armature resistance (Ohm) 9.30 2.79 1.55 0.93 0.42 1.34 0.897 0.20 0.13 Armature inductance (mH) 24.0 12.07 6.71 7.39 3.53 7.55 5.7 1.81 1.50 Electrical time constant (ms) 2.58 4.30 4.30 7.96 8.36 5.66 6.35 9.30 11.4 Insulation class Class A (UL), Class B (CE) Insulation resistance >100M?, DC 500V Insulation strength 1500V AC, 60 seconds Weight (kg) (without brake) 0.5 1.2 1.6 2.1 3.0 2.9 3.8 4.3 6.2 Weight (kg) (with brake) 0.8 1.5 2.0 2.9 3.8 3.69 5.5 4.7 7.2 Max. radial shaft load (N) 78.4 196 196 245 245 245 245 490 490 Max. thrust shaft load (N) 39.2 68 68 98 98 98 98 98 98 Power rating (kW/s) (with brake) 25.6 21.3 53.8 22.1 48.4 29.3 37.9 30.4 82.0 Rotor moment of inerti0.81a (x 10-4kg.m2) (with brake) 0.04 0.192 0.30 0.73 1.18 1.95 2.67 3.33 4.95 Mechanical time constant (ms) (with brake) 0.81 0.85 0.57 0.78 0.65 1.74 1.22 0.93 0.66 Brake holding torque [Nt-m (min)] 0.3 1.3 1.3 2.5 2.5 2.5 2.5 8.0 8.0 Brake power consumption (at 20°C) [W] 7.2 6.5 6.5 8.2 8.2 8.2 8.2 18.5 18.5 Brake release time [ms (Max)] 5 10 10 10 10 10 10 10 10 Brake pull-in time [ms (Max)] 25 70 70 70 70 70 70 70 70 Vibration grade (um) 15 Operating temperature 0°C to 40°C Storage temperature -10°C to 80°C Operating humidity 20% to 90% RH (non-condensing) Storage humidity 20% to 90% RH (non-condensing) Vibration capacity 2.5G IP rating IP65 Servo Drive and Servo Motor Combinations Power Servo Drive Servo Motor 100W ASD-B2-0121-B ECMA-C20401_S(S=8mm) 200W ASD-B2-0221-B ECMA-C20602_S(S=14mm) 400W ASD-B2-0421-B ECMA-C20604_S (S=14mm) ECMA-CM0604_S (S=14mm) ECMA-C20804_7 (7=14mm) ECMA-E21305_S (S=22mm) ECMA-G21303_S (S=22mm) 750W ASD-B2-0721-B ECMA-C20807_S (S=19mm) ECMA-C20907_S (S=16mm) ECMA-G21306_S (S=22mm) ECMA-GM1306_S (S=22mm) 1000W ASD-B2-1021-B ECMA-C21010_S (S=22mm) ECMA-C20910_S (S=16mm) ECMA-E21310_S (S=22mm) ECMA-G21309_S (S=22mm) ECMA-GM1309_S (S=22mm) 1500W ASD-B2-1521-B ECMA-E21315_S (S=22mm) 2000W ASD-B2-2023-B ECMA-C21020_S (S=22mm) ECMA-E21320_S (S=22mm) ECMA-E21820_S (S=35mm) 3000W ASD-B2-3023-B ECMA-E21830_S (S=35mm) ECMA-F21830_S (S=35mm) Applications Transportation Machine, Cutting Machine, Lathe and Milling Machines Other hot items of this B2 series for above applications: ECMA-C20602ES Delta AC Servo Motor B2 Series ECMA-C20602ES 60mm 220V/3000rpm Keyway 200W New ECMA-C20602FS Delta AC Servo Motor B2 Series ECMA-C20602FS 60mm 220V/3000rpm Brake/Keyway 200W New ECMA-C20602RS Delta AC Servo Motor B2 Series ECMA-C20602RS 60mm 220V/3000rpm keyway/Oil Seal 200W New ECMA-C20604PS Delta AC Servo Motor B2 Series ECMA-C20604PS 60mm 220V/3000rpm Keyway 400W New ECMA-C20604RS Delta AC Servo Motor B2 Series ECMA-C20604RS 60mm 220V/3000rpm keyway/Oil Seal 400W New ECMA-C20604SS Delta AC Servo Motor B2 Series ECMA-C20604SS 60mm 220V/3000rpm keyway/Oil Seal/Brake 400W New ECMA-C20804R7 Delta AC Servo Motor B2 Series ECMA-C20804R7 80mm 220V/3000rpm keyway/Oil Seal 750W New ECMA-C20807R6 Delta AC Servo Motor B2 Series ECMA-C20807R6 80mm 220V/3000rpm keyway/Oil Seal 750W New ECMA-C20807RS Delta AC Servo Motor B2 Series ECMA-C20807RS 80mm 220V/3000rpm keyway/Oil Seal 750W New ECMA-C20807SS Delta AC Servo Motor B2 Series ECMA-C20807SS 80mm 220V/3000rpm keyway/Oil Seal/Brake 750W New ECMA-C21020RS Delta AC Servo Motor B2 Series ECMA-C21020RS 100mm 220V/3000rpm keyway/Oil Seal 2000W New ECMA-C21020SS Delta AC Servo Motor B2 Series ECMA-C21020SS 100mm 220V/3000rpm keyway/Oil Seal/Brake 2000W New We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Delta
MPN	ASD-B2-1521-B + ECMA-E21315SS
Model	ASD-B2-1521-B + ECMA-E21315SS
Country of Manufacture	Taiwan, Province of China
