Delta Unisaw Replacement Cam For The Fence Rear Clamp - 4130 Chromoly Steel

US $3075

Freeland, Michigan, United States
Jun 4th

Open on mobile:
QR code

Is your Delta Unisaw Jet-Lock fence not "locking" the rear clamp like it should? It could be due to a damaged lever in the rear clamp casting. This part is an exact replacement for the original equipment cam lever that is located inside the casting at the rear of the rip fence. This small lever is actuated by the operator to clamp the fence at the rear rail on a Delta Unisaw. Original equipment cam levers were made of mild steel and were prone to distortion when the fence clamp was over-tightened or improperly adjusted. Our cam is an exact copy of the Delta cam, but is laser cut from 4130 chromoly steel. 4130 chromoly steel has a yield strength of 120,000 psi as compared to the 30,000 psi yield strength of the OEM mild steel cam. The pivot hole was then precision reamed to the correct diameter and deburred. Our replacement cams are now black oxide plated for increased corrosion resistance. The black oxide finished cams are shown in Photo #2. The newer style Jet-lock fence, with the single lever that secured both the front and rear of the Unisaw fence in one motion, was Delta's "better" idea. The slotted screw above the lever was present to preset the J-hook's clearance to the rear rail so that when the lever was pushed down to lock the front of the fence, the fence's internal cast iron lever's stroke would snug up the rear clamp. However, adjustment of the rear clamp clearance was tricky and easily set too snug. If the clearance set by the slotted nut was inadequate, the rear clamp would immediately tighten.... and as the front lever completed its stroke, the cam inside the rear clamp block would be bent. Once that happened, restoring the rear clamp's intended function would be nearly impossible, depending on how much the cam had deformed. Earlier fences were less prone to this problem. On early fences, the operator tighened the rear clamp with his fingers using a small fluted knob above the front clamping lever. It would be nearly impossible to distort the rear clamp cam with only finger pressure on this hard-to-grip little knob. Installing our direct replacement cam lever is simple and easy, and will restore the function of your Delta fence rear clamp. Only the cam lever is for sale in this listing. The assembly drawing and the exploded view of the rear clamp block components are for reference only, and to show where and how the cam lever fits into the rear clamp block. FREE SHIPPING Shipping is FREE to anywhere in the lower 48 states. Shipping to other locations will be calculated based on zip code and quoted before payment is accepted.. Payment by PayPal is preferred. Payment must be received within five days of the auction close. If our other Delta Unisaw, conventional table saw, and other Delta equipment items are not currently listed on eBay, please contact us. We manufacture and offer the following parts for improving, upgrading, and/or restoring your vintage Delta Unisaw or shaper: Hard-to-find LH threaded arbor nuts A new and improved blade wrench A unique "no-drill" wrench hanger Replacement knobs for your Unisaw fence Replacement knobs for the dust door and hand wheel locks Improved Allen bolt rail mounting kit A heavy duty billet aluminum miter fence New stainless steel Unisaw and Delta Mfg switch plates New stainless steel vertical Delta dust door nameplate Replacement Delta Unisaw and shaper toggle switches Replacement brass bullets for the vertical and tilt lock shafts A replacement fluted knob for the rear fence clamp Replacement fluted knobs for the micro adjustment at the fence... and for the Unisaw's handwheel locks and dust door Economical replacement dust doors A billet aluminum rear fence clamp block and spring return kit Delta OEM fence rear clamp blocks New “Saturn” knobs and stainless shafts for your Jet Lock fence lock Vintage Delta motor nameplate decals Dealer inquiries are welcome. Quantity inquires will get attention. We will build to order on request. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
