Curing Light Handpiece Dental Burs Files Orthodontic Air polisher Teeth Model Scaler Dental Wireless X ray Machine BLX-8 crystal-clear images Technical Parameters 110v±10% and 220V±10% (We stock the item specail for the customer all over the world) Power: 24V 8000MA Charger: 220V/110V, 50Hz Tube current: 0.1mA Rating: 60W Frequency: 30 KHz Exposure time: 1-9 seconds optional Leak radiation: < 20µgy/h(12lb) Focus Skin Distance: >20cm Tube voltage: 70KV Relative Humidity(RH) < 80% Storage conditions: 5-40 degrees Celsius, relative Humidity Net weight: 2.5 kg Feature 1, Low amount of radiation, safeguards patients and staff from overdoes of radiation exposure. 2, Delivers fast response speeds and higly-accuracy output indexes 3, Wireless, can be charged. 4, Uses Toshiba 0.3 micro-focus tube, ensuring crystal-clear images. 5, The excellent radiation-shield protection for tube head 6, High-frequency design makes unit portable and compact, saving you space, easy to carry. 7, CE Certification, ISO9001 Quality Certification Package list 1 X Main Unit 1 x Dental Film Position Indicator 1 x Charger 5 x Dental Films for Commissioning 1 x Packing Instruction 1 x Warranty Card 1 x Large Packing Box 2 x Key of the packing box Operation of the Main Unit ?Upon receiving,open the box and check the product for possible damage during shipping. ?Make sure the fittings on the encasement list are packaged within the box. ?Install the blue ray tube to the foreside of the ball head,then tighten it. ?Turn on the Power;the pilot lamp will be light up.During this time,the digital tube will show the fore setting time. Now the equipment is in standby mode. Setting the time ?(Skip to next step if unneeded) Use the "SET","+",and" -" buttons to reset the time as follows: press SET,the pilot lamp above is illuminated, the machine is now in the time setting mode->then press "+" and" -" to set the time needed (time range is 1-9seconds); press set again when the time is adjusted the light lamp is off. The equipment is now in standby mode. ?Put the Tooth film plumb behind the tooth which is going to be taken picture, and be as close as possible (the smooth side stick to the tooth) ?Keep the ball head plumb to the tooth projection position; Have the ball head,tooth, and tooth film steadily mutually plumb. After positioning,use the ON/OFF on the main Unit, to take pictures. (Notice: gently press 0.5 sec to turn it on)After exposure to the tube,press the start button again in case of an emergency to stop shooting and return to standby status. (At this point there was no output ray,so the dental films can be used again). ?Repeat step 6 to reset the picturing time.To repeat the picturing process,please repeat steps 7 to 9.Turn the power off when the work is finished,press POWER, making sure the pilot lamp is off.Don't keep the machine long in standby mode. Developing the Dental film ?Picture the tooth following the right operating procedure of the X-ray Unit,then take the film out from the mouth. ?Use a syringe to extract 4-5 mi of imaging liquid. ?Transfuse the liquid into the bag,nip both the ends and the sides of the bag with thumbs and first fingers(knead the film). ?Open the end of the bag about ten minutes after transfusing the liquid into the bag. ?Take the film out,put it into clear water,and rinse it. Don't wipe the surface of the film with the surface to prevent damage to the image. ?Observe and diagnose after the film becomes dry. Points for Attention 1. Make sure the angle of film,tooth,and ball head are properly aligned when taking a picture. Keep them steady until the last step of picturing; making sure that there is no change in any of their positions. 2. Remember to turn the power 0ffwhen work is done. 3. Charge the battery if the machine cannot work and the red lamp lignt 4. After turning the power on, wait one minute before taking pictures,this allows the ray to provide a steady output. 5. The equipment switches into protection mode automatically when the voltage is incorrect. If this occurs, it will not be able to carry out the normal work of filming. 6. When taking pictures,the ON/OFF button could stop the objection and then the machine goes back to the preparation mode. 7. Use high quality tooth film and developing liquid to make clear pictures. Handle the ball head gently while in use,so as not to damage the delicate component. 8. We usually set the time between 3-8 seconds when taking pictures, but the actual time of ray output is 0.2-0.5 seconds. 9. If a situation occurs, preventing the machine from taking regular pictures, contact the seller to solve the problem instead of trying to service the product yourself. 10. Keep the tooth film and the liquid in a proper place and use them within the shelf-life period. 11. Development of films should be performed at temperatures ranging between 23-25 degrees Celsius to ensure the image quality. 12. Other requests accordance with the scope of the technical parameters. Please read the manual carefully before using. Warranty We offer a 1 year warranty as follows. (Note: When warranty expires,we charge for the replacement and repairs of the machine and components.) The following cases are not within the scope of this warranty: Intentional damages to the machine which cannot be repaired. Opening the machine for purposes of reverse engineering for means of imitation. Getting burned using the wrong power supply. Modifications to the machine,such as the addition of extra components to the machine resulting in damage that prevents the normal use The Angle should be proper while taking a picture. The film should be put vertically behind the tooth to be taken a picture while the case is for the front teeth; and the film should be put transversely behind the tooth to be taken a picture while the case is for the back teeth. The patient should use forefinger to press the film behind the tooth gently. *Kodak film as the sent samples are strongly recommended. 1. Not receive a timely reply? Our working hours are Monday to Friday GMT am8 :30-pm5 .30, we will reply your mail as soon as possible during working hours. 2.After two inquiries goods transport. We will refer to the correct URL to your query letter delivery. 3. product damage and warranty Normal mechanical products, such as mobile phones, scaler, light-cured and some other product warranty period is three to six months. 4. More than 2-3 months did not receive the goods Under normal circumstances, the transport time of the United States 15 days, about 25 days in Europe, Australia, 30-35 days, 50-60 days South America time. I hope you can understand the international transit there are many uncertain factors beyond our control, such as a little bad weather, the Customs to detain the reason and so on, we will try to help you solve all your problems. Shipping Payment Feedback Returns Contact Us The goods you odered will be posted out in the second working day after the paymet has been made. (We will inform you via email if any delay occured due to holiday events. General shipping time is between 7-12 working days. (After the shipping started, the order will be monitored and the track of the item will be posted on paypal. Destination Delivery Time Working Days 7-10 10-15 15-25 25-40 >50 US Item arrived 80% 10% 8% 1% Refund ASIA Item arrived 30% 40% 20% 10% Refund EU Item arrived 20% 20% 50% 10% Refund AU Item arrived 30% 30% 20% 20% Refund other countries Item arrived 5% 10% 10% 60% -- We accept PayPal and bank wire transfer. All payments must be made within 7 days after the auction ends. Non-paying bidders will be reported to eBay. Please don't buy an item if you can't/won't pay for it. Paypal is the easiest way to pay for items on eBay. Please make sure your Paypal and eBay accounts have the same physical address used for delivery and the same e-mail address to ensure payment confirmation. Shipping: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. You feedback is VERY important to us Please leave us positive feedback, an positive feedback will be automatically left for you once we receive your full payment. Please leave us with any concerns prior to leave negative feedback, as we can only correct issues when we are aware of them. We understand the concerns and frustrations you might have, and will try our best to resolve the isuues. If the item you received is damaged or defective,Please contact us immidately.We will free exchange or refund. We will pay the return shipping costs if the product is defective or the return is a result of our error. If the item is returned for any other reason you are responsible for the return shipping charges. You can return your purchase for up to 15 days from the date of delivery. No refund will be issued if the product shows signs of use. Returned package must be in the original packaging, everything must be in new condition, No missing parts. Our guarantee does not cover accidental damage or wear of product caused by customer.Thank you very much for your understanding! Serivce is our #1 priority at BAISTRA! If you contact us immediately after placing the order, we will make every effort to assist you with your change request. Unfortunately, we can not make changes or cancel an order once it has shipped. We offer the best items at the best prices. We strive to exceed all your expectations and put a smile on your face. Your experience will be a pleasant and effortless one when you buy at PiercingPros. We stand behind our products and pride ourselves on OUTSTANDING customer service. We guarantee that you will be delighted with your purchase or we will gladly and promptly issue you a refund or make things right! On Jun-18-14 at 02:02:16 PDT, seller added the following information:
