Devar Sm812-1 100? Pt 2-wire Rtd, Hazardous Location Thermal Well

US $290

Minneapolis, Minnesota, United States
Jan 29th

Open on mobile:
QR code

INCLUDES: ONE TEMPERATURE PROBE SM812-1 150DEG. F - 300 DEG F. INSTALLED IN HAZARDOUS LOCATION THERMAL WELL DEVAR Inc. Model SM812-1 2-WIRE RESISTANCE TRANSMITTER MANUAL NO. 990627 REV. C SPECIFICATIONS Performance Input:......................................... Standard 100? Pt RTD, ? = 0.00385 Output Signal Range:................. 4 to 20 mADC Open RTD Indication Output:.... >22mA Absolute Limit:........................... 2 to 25 mA Accuracy:................................... ± 0.1% / span, includes effects of linearity, hysteresis, and repeatability referred to temperature input. Nonlinearity:.............................. 0.1% relative to a 100? Pt RTD, ? = 0.00385 Frequency Response:............... Output –3dB @ 3Hz Input Thermal Effect Zero Shift:.................................. ± 0.02% / Span/°F Span Shift:.................................. ± 0.02% / Span/°F Power Supply Working Voltage:....................... 8.5 to 35 VDC Supply Voltage Effect:............... < ± 0.001% / Span / Volt Loop Considerations Loop Resistance Load Effect:... < ± 0.002% / Span / 300 Ohms Maximum Loop Resistance:...... MLR(?) = (VSupply – 8.5V) / 0.020A RFI Immunity Rated Class 3-C:........................ 0.25% of span per SAMA PMC 33.1-1987-2abc Environment Temperature Range:.................. Ambient –13° to 185°F Storage –85° to 257°F Humidity:................................... 0 to 90% non-condensing Calibration Range Zero:.......................................... Minimum to Maximum in 2 segments Span:......................................... Minimum to Maximum in 8 segments Options SM812-0001 Zero Range -40/40°F, Span Range 150/500°F -M31S SnapTrack™ Mounting Bracket -M31D DIN Rail Mounting Bracket -CHN Nylon Connection Head -CHA Aluminum Connection Head -CHAS Flip Top Connection Head -CHX Explosion Proof Connection Head -RTDSF Spring Loaded RTD (Specify Length) -RTDBF Brazed RTD (Specify Length) -JB Add Junction Box with Sensor DIP SWITCH FUNCTION ZERO ADJUSTMENT POSITION 4 ON OFF ZERO RANGE –40°F to –1°F 0° to 40°F SPAN SELECTION POSITION 3 ON ON ON ON OFF OFF OFF OFF POSITION 2 ON ON OFF OFF ON ON OFF OFF POSITION 1 ON OFF ON OFF ON OFF ON OFF Model -0001 150°F 200°F 250°F 300°F 350°F 400°F 450°F 500°F TYPICAL INSTALLATION CALIBRATION PROCEDURE 1) Required test equipment: a) Current measurement method with basic accuracy of 0.04% and resolution of 1?A. b) Power supply, 22 mA minimum. 24 VDC desired, 8.5V to 35V, depending on load resistance. c) RTD simulator accurate to within ± 0.5°F. The RTD can be simulated by decade resistor substitution box set to the appropriate values for the desired calibration. A table identifying the RTD temperature response is available upon request. 2) Identify transmitter temperature range by referencing the dash number and the DIP switch setting of the particular unit. Refer to the table on the next page. 3) Connect the device under test and the required test equipment as outlined on the attached wiring diagram. 4) Set the RTD simulator for the calibration range minimum temperature and adjust the Z(ero) potentiometer to obtain the minimum output of 4.000 mA. 5) Set the RTD simulator for the calibration range maximum temperature and adjust the S(pan) potentiometer to obtain the maximum output of 20.000 mA. 6) Repeat steps 4) and 5) until the device under test reads true without further adjustments. MCID# 52503 Check out my other items! Any Questions Call or email or Stop In We accept Paypal and Wire Transfers Have a Blessed Day! Paul Open Monday - Friday 8-5 Paul Sullivan METRO CAD, INC. 8808 Monticello Lane North Maple Grove, Minnesota 55369 USA 763-595-7307 Phone 763-595-7311 Fax Used Equipment Sales New Equipment Sales KILOTECH Scales EZ Maintenance PM & Calibration Software Job Master Manufacturing Software Rigging, Moving, Storage and Archival Sold "as is, where is" Cost for Packaging and shipping are the buyers responsibility. Shipping Please call or Email S&H and Crating Fees will apply Additional fees for outside the US shipment. Notice: Some items offered for sale are restricted from shipment to an ultimate destination outside of the United States, by U.S. Law. All sales of these "Restricted Technology" items are intended for ultimate destination only within the U.S. and it is the sole responsibility of the buyer to obtain proper licenses, where required, and if allowed, by U.S. law. Warranties While descriptions are believed to be accurate, the sellers make no warranties or guarantees, expressed or implied, as to the genuineness, authenticity of, or defect of any item(s) being sold and will not be held responsible for any advertising discrepancies or inaccuracies, including without limitation any pictures, descriptions or other information relating to the assets as contained on the website metro-cad or other communications electronic or otherwise. All items are sold on an "AS-IS", "WHERE IS", AND "WITH ALL FAULTS" basis. THE SELLER MAKES NO WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED AS TO THE NATURE, QUALITY, and VALUE OR CONDITION OF THE GOODS OR ITS SUITABILITY FOR ANY USE. SELLER EXPRESSLY AND SPECIFICALLY DISCLAIMS WITHOUT LIMITATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. BUYER AGREES THAT THE SELLER SHALL NOT BE LIABLE FOR SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES. Disclaimers It is the buyer's responsibility to secure all safety equipment to meet all applicable government safety and environmental standards in using, removing or shipping the items purchased. Certain pieces of equipment may contain residual chemicals. The purchasers hereby indemnify and hold harmless the sellers from any and all damages, claims, or liabilities from any injuries to persons or property of any type whatsoever caused during the sale or during the removal or during use or operation of the purchased items. Effort has been made to provide accurate information and photo to match the items, however, there may be inaccuracies in the information and there may be errors or substitutions in photo matching. METRO CAD INC. will try to provide resolution to these inaccuracies as we are made aware of them but assumes no responsibility for any inaccuracies, including without limitation any pictures, descriptions or other information relating to the assets as contained on the website, metro-cad, or other communications, electronic or otherwise. It is buyer's responsibility to keep updated on bidding and terms and conditions. METRO CAD INC. reserves the right to modify Terms and Conditions for bids and sales from time to time, without prior notice. Click on a picture to enlarge Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“This was a sales Display unit”
