Dfrobot Arduino Compatible Motor Shield (2a)

US $16.64

Swanton, Vermont, United States
Jul 28th

Open on mobile:
QR code

Description Uses L298P chip which allow to drive two 7-12V DC motors with maximum 2A current Logic Control Voltage:5V Can be directly mount onto standard Arduino Duemilanove and Arduino Mega Strongly encouraged to use external power supply to power the motor shield The DFRobot Arduino Compatible Motor Shield (2A)uses L298P chip which allow to drive two 7-12V DC motors with maximum 2A current. This shield can be directly mount onto standard Arduino Duemilanove and Arduino Mega. The speed control is achieved through conventional PWM which can be obtained from Arduino's PWM output Pin 5 and 6. The enable/disable function of the motor control is signalled by Arduino Digital Pin 4 and 7. The Motor shield can be powered directly from Arduino or from external power source. It is strongly encouraged to use external power supply to power the motor shield. Specifications Logic Control Voltage: 5V (From Arduino) Motor Driven Voltage: 6.5 - 12v(VIN Power Supply),4.8 - 35V (External Power Source) 2 way motor drive Logic supply current Iss: ≤36mA Motor Driven current Io: ≤2A Maximum power consumption: 25W (T=75º) Up to 2A current each way Pin 4,5,6,7 are used to drive two DC motor Support PWM speed control Support PLL advance speed control Size: 55 x 55mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	DFRobot
Type	DFRobot
MPN	DRI0009
UPC	Does not apply
EAN	6959420900039
