Dfrobot Mega 2560 With Multi-channels Data Acquisition, Io Control & Data Logger

US $32.90

Puchong, Selangor, Malaysia
Jan 29th

Open on mobile:
QR code

Introduction: This is the DFRduino Mega 2560 V3.0 from DFRobot. It is fully compatible with Arduino Mega 2560 R3. By implementing the SmartDAQ firmware, this board becomes a powerful device which can stream data from multiple channels, control output and log data via smartphone device at any where and any time. Introduction - DFRduino Mega 2560: NEW VERSION! This is the upgraded DFRduino Mega 2560 V3.0 which is now fully compatible with Arduino Mega 2560 R3. The Arduino Mega is a microcontroller board based on the ATmega2560. It has 54 digital input/output pins (of which 14 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header and a reset button. It contains everything needed to support the microcontroller; Connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Mega is compatible with most shields designed for the Arduino Duemilanove, Diecimila or Uno. One cool thing about our DFRduino microcontrollers is that the hearders with different colors are used to differentiate I/O ports in an relatively easy way: Red indicates Power Section Blue indicates Analog I/O Green indicates Digital I/O. This kind of correspondence match exactly the same with our sensors, making it even cooler and more user-friendly. The R3 board enjoys following new features: Added SDA and SCL pins that are close to AREF pin and two other new pins close to RESET pin, allowing voltage adaptation with IOREF. Our shields will be fully compatible both with the AVR boards operating @5V and Due @3.3V in future. Improved RESET circuit Replacing the Atmega 8U2 with Atmega 16U2 (datasheet) Introduction - SmartDAQ: SmartDAQ is a power Android app used to perform multiple channels control and monitoring. By using SmartDAQ, user can easily read data and control output from microcontroller via smartphone device in any where and any time. Features of SmartDAQ are same as follow: Analog signals reading in voltage unit Digital signals input reading or output control Colorful icon to display value high, low, analog input and PWM setting Extra title input for each pin Display multiple signal in graph Record data into file every second Allow user to select the pins to display Share/Send logged data file by email Delete logged data without using external App This package includes: 1 x DFRduino Mega 2560 V3.0 with full version SmartDAQ firmware (16 Analog Pins & 58 Digital Pins) Technical Specifications: Compatible with Arduino Mega 2560 R3 Microcontroller: ATmega2560 Operating Voltage: 5V Input Voltage (recommended): 7 ~ 12V Digital I/O Pins: 54 (of which 14 provide PWM output) Analog Input Pins: 16 DC Current per I/O Pin: 40 mA DC Current for 3.3V Pin: 50 mA Flash Memory: 256 KB of which 8 KB used by bootloader SRAM: 8 KB EEPROM: 4 KB Clock Speed: 16 MHz Download: Mega v3.0 Schematic:Link Mega v3.0 Layout:Link Atmega 2560 datasheet:Link SmartDAQ: Link Tutorial to use Free version SmartDAQ(Android) for ARDUINO MEGA 2560: Link Shipping: Standard Shipping (Delivery time is 7-30 business days): with Registered Air Mail Expedited Shipping (Delivery time is 3-10 business days): is available to US, Canada, Europe & Australia. P.O. Box is not supported for expedited shipping Expedited Shipping for Europe countries ONLY cover: Austria, Belgium, Czech, Denmark, Finland, France, Germany, Hungary, Ireland, Italy, Liechtenstein, Luxembourg, Monaco, Netherlands, Norway, Poland, Portugal, Slovakia, Spain, Sweden, Switzerland And United Kingdom Please check with us of express shipping for other countries. Tracking number is provided for Standard and Expedited Shipping. You may contact us for the tracking number. We ship within two business day after payment received. We will ship to the Paypal shipping address you entered during checkout process, rather than your eBay shipping address. We Ship to Worldwide, except China and Israel. Payment Payment method: We only accept PayPal Please request total for combined orders. Other Policies We are not responsible for any custom duty or import tax. These charges are the buyer's responsibility. We will leave POSITIVE FEEDBACK after receive the full payment. Please contact us if you are not satisfied with the item when you receive it. Serious Buyer Only! Please place bid only if you agree with all the terms. Warranty 6 months Warranty. Buy with confidence! Only MANUFACTURING defective product will be offered exchange or store credit. Damage caused by any misuse of product is not covered under warranty. Contact Us Please read our policy and product description before your purchase. We will explain it in detail and satisfy your needs. Feel free to contact us! Email: support@avrcircuit.com For more information, please visit www.avrcircuit.com apps.froo.com | Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application
