Diamond Engineering Antenna Measurement System, Model 5100, US $7751 – Picture 0
Diamond Engineering Antenna Measurement System, Model 5100, US $7751 – Picture 0

Diamond Engineering Antenna Measurement System, Model 5100

US $7751

  • Temple, Texas, United States
  • Jun 9th
Open on mobile:
QR code
Complete unused system is $21,000 from the manufacturer:    Link:   ramayes.com/Data%20Files/Diamond%20Engineering/Diamond_Engineering_Brochure.pdf Downloadable brochures available at RAMayes or Diamond Engineering websites. Instrument opened only to verify completeness and take photos.  Please email questions. Serial #  2012010 DAMs 5100 Heavy (Alum) DAMs platform 150lb load USB Interface Control Box - 25ft Cable Az & El Removable 24" Aluminium Thrust Plate Software: Advanced Software for PC (PC not included) Spherical Plotting / Isotropic & Dipole Ref Software GPIB interface (card not included) Laser pointing SMA mount Vertical Alignment Level Az Movement: ± 435° with 1/4° resolution El Movement: ± 90° with 1/4° resolution Measurement Features-Real-Time measurement display of current gain @ position. -Ideal Antenna Overlay for antenna comparison. -Completely De-Embedded Measurements (full calibration- no outside interference) Of Antenna Data Only. -Data Export with Variable Format option -Measure up to 2800 points per frequency in one 360 degree sweep. -variable speed. -Move to Max Position. -Vertical/Horizontal Combination Sweep Measurements. -CW/CCW Antenna rotation. Visualization Features -All Plots operate in Real-Time -Printable Plots -Resetting Amplitude Plot -Non-resetting History Plot -Polar Radiation Plot -Instant support system -Color Coded measurement controls -3D plots (only available with Advanced Processing Add-on) -Real-Time Measurement Status
