Digital 1.2~225mm Metal Ul Gm-100 Trasonic Thickness Meter Tester Gauge Velocity

US $63.00

sz, China
Jan 30th

Open on mobile:
QR code

The Digital Ultrasonic Thickness Gauge is an intelligent that adopts ultrasonic measuring principle. Controlled by micro processor, offers immediate and precise measurement of thickness for most of industrial material. The measurement range of 1.20~225.00mm combined with ultrasonic wave velocity measurement function of 1000~9999m/s provides accurate measurement readings. Widely used in various precise measurements for different hardware/parts in industrial realm. One of its important applications is to monitor the level decreasing thickness during operation of various and pressure container. Diffusely applied in manufacture fields, metal processing as well as commercial inspection and can be applied for materials that conduct and reflect constant sonic velocity. Features: Auto Calibration to assure the accuracy Auto linear compensation: this advanced software program enhances the precision by correcting the non-linear accuracy of transducer Use ? and ? keys to make a quick adjustment for the sound velocity/thickness and a quick recall to the stored data Coupling status indication: Observing the coupling icon to learn if the coupling is accomplished or not 10 thickness measurement storage and recall function available, which facilitated the height work or working in wild area Sound velocity measurement: with a given thickness by a sample hardware to measure the sound velocity, which avoid the further conversion or consultation of the table 12 sound velocity for different material which also adjustable Low battery indication Auto power off mode designed to conserve battery life More than 10000 times long life keys The unit has a special memory that retains all of its setting even when the power is off General Specifications: LCD Digital display: 4 digits Minimum display unit: 0.1mm Working frequency: 5MHz Measurement Range: 1.2~225.0mm (Steel) Minimum limit for Tubes measurement: ?20 x 3mm (Steel) Accuracy: ± (1% H + 0.1 mm) (H denotes the measured thickness) Sound Velocity Range: 1000~9999m/s Measuring Sound Velocity with a given thickness Measuring Range: 1000~9999m/s When the given thickness over 20mm, the accuracy is ±1%; when the given thickness less than 20mm, the accuracy is ±5% Operating Temperature: 0~40°C (32~104°F) Power supply: 3 x 1.5 AAA Alkaline Batteries (Not Included) Operation Current: Normal Operation Current
