Digital Frequency Synthesizers Frequency Waveform Pulse Function Generator 2mhz

US $65.17

Guang Zhou, China
Jan 29th

Open on mobile:
QR code

Triangle/Square/Sine Wave Digital Frequency Synthesizers Frequency Waveform Pulse Function Generator 0.01Hz-2MHz #090958 Product Description Features: 1. Frequency resolution: 0.01Hz 2. Frequency Accuracy: ± 20ppm (plus or minus 20 ppm 3. Low Distortion: <1% 4. Square wave 1% to 99% duty cycle precisely adjustable 5. Triangular wave modulation duty cycle output two kinds of sawtooth after 6. Variable DC level control 7. External Frequency Measurement 8. The default frequency is stored, transferred functions 9. Interface 10 Dimensions: 130 (depth) * 102 (W) * 85 (maximum height) mm Output function signal (main signal output): Output: TTL Input: external count Main Output waveforms: sine, square, triangle wave, sawtooth Maximum output amplitude: 10Vpp (no load) Output impedance: 50Ω ± 10% DC Offset: ± 2.5V (no load) Duty cycle range: 1% -99% (square wave) Display: LCD1602 Output frequency range: Sine wave: 0.01Hz-2MHz Square wave 0.01Hz-1MHz (the valid range) Triangular wave: 0.01Hz-1MHz (the valid range) Sawtooth: 0.01Hz ~ 1MHz (the valid range) Resolution: 0.01Hz Frequency Stability: ± 1 × 10-6 Frequency error: ± 5 × 10-6 Sine Wave Distortion: <1% (reference frequency 1kHz) Triangle wave linearity: ≥ 98%, 0.01Hz ~ 100kHz; ≥ 95%, 100kHz ~ 1MHz; Square wave rise and fall time: <30ns TTL output: TTL level ≥ 3 Vp-p With a load capacity: 20TTL load Outer measurements: Frequency range: 1Hz-60MHz Signal amplitude: 0.5Vpp-20Vpp Outside the counting range :0 -4294967296 Storage and transferred: 10 set of parameters with storage and recall functions. Requires a detailed user manual, please contact us Package Includes: 1x Signal Generator 1x DC5V Power Supply 1x USB cable 1x Q9-Clip Line Payment Method We accept only Paypal for both domestic and international. We will ship to the shown address on you PAYPAL Payment notice,Please confirm your shipping address in the PayPal Account. If buyer want to delay the payment because of financial problem, please contact me by the ebay message within 3 days. Shipping Detail Ship by Post Air-mail within 3 working days after full payment is received. The shipment usually takes 15-45 business days to Worldwide. We also provide international Expressed delivery such as EMS, DHL and UPS,extra shipping fees is needed. The shipping time may vary, depends on receiver's location. Feedback Policy We will leave positive feedback to buyer as soon as buyer pays for the item. Leaving Negative feedback or Netural Feedback is never a good way to resolve problem .We hightly appreciate that you can contact with us before you leaving Negative feedback or Neutral feedback .We will offer help to resolve your problems as fast as possible. Customer Service Work Time If you have any questions,Please contact with us via eBay message or our customer service e-mail . please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 11:00 - 20:00 and Saturdays 11:00 – 15:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) Engineered for professional eBay sellers! On Nov-26-14 at 12:46:52 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Main Output waveforms	sine, square, triangle wave, sawtooth
Resolution	0.01Hz
Output Sine wave range	0.01Hz-2MHz
Duty cycle range	1% -99% (square wave)
Output Square wave range	0.01Hz-1MHz (the valid range)
Display	LCD1602
Output Triangular wave range	0.01Hz-1MHz (the valid range)
Dimensions	130 (depth) * 102 (W) * 85 (maximum height) mm
Output Sawtooth range	0.01Hz-1MHz (the valid range)
