Digital Led Esr Meter Component Transistor Tester Diode Triode Capacitance New

US $38.60

shenzhen, China
Feb 15th

Open on mobile:
QR code

Digital LED ESR Meter Component Transistor Tester Diode Triode Capacitance New 1 Digital LED ESR Meter Component Transistor Tester Diode Triode Capacitance New Description: Features: Automatic identification devices. Automatically determine the pin. Automatic measurement parameters. 12864 graphics display. more details: Dimensions: 70mm * 135mm * 24mm Power: DC9V (9V battery 6F22) Weight:128g (without battery) NEW Function: 1. Automatic detection of NPN and PNP transistors, n-channel and p-channel MOSFET, diode (including double diode), thyristor, transistor, resistor and capacitor and other components 2.it Automatic test the pin of a component, and display on the LCD 3.it Can detect the transistor, MOSFET protection diode amplification coefficient and the base to determine the emitter transistor forward biased voltage 4. Measure the gate and gate capacitance of the MOSFET threshold voltage Specifications: For you reference 1,One -button operation, automatic shutdown . 2,Only 20nA shutdown current. 3,Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4,Automatic identification components pin arrangement . 5,Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6,Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7,Can detect bipolar transistors and MOS transistors protection diodes. 8,Measuring the gate MOS FET threshold voltage and the gate capacitance. 9,Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 . Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position , we can distinguish the middle and both ends of the pin. 10,Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11,Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12.2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13,Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14.LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15,Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16,Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , it can measure the collector or emitter junction reverse capacitance . 17 can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter . 100% Brand New Include: 1PC Component tester(not include battery) Payment Payment : We accept paypal Credit card payments must be made through PayPal. We recommend you to sign for a PayPal account before bidding. We will Not take responsible on Customs duty if any Shipping time : Shipping time : If you haven't get your parcel within the expected date,Pls contact with us directly.We can ensure solve it for you .Pls trust us .We need your support. Thanks .Yours Sincerely. Country Shipping Time Refund or Resend 80% 12% 5% United States United Kingdom Australia /Canada 10-20 working days 25 working days 27 working days >27 working days Singapore Other Asia country 15-25 working days 28 working days 32 working days >32 working days Germany /France Austria /Netherland Poland 20-30 working days 33 working days 36 working days >36 working days Spain Russia 25-35 working days 37 working days 40 working days >40 working days Others 25-35 working days 37 working days 40 working days >40 working days Feedback Feedback : We would appreciate receiving your 5 stars positive feedback.If there's any dissatisfaction with your parcel ,pls contact with us before you leave the feedback .We can solve it for your perfectly.Thanks for your understanding and help. Return Policy 1. All items are checked and packed in good condition before dispatch. 2. If you find any defect in our items, please contact us within 14 days of receipt item. 3. Return items must not be used. 4. Buyer is responsible for all return shipping charges. We will return all your money except the shipping and handling fees or make exchange for you after we receive your return items. Please do not ship the item back to us without our confirmation. Thanks Contact us SHIPPING TERMS: Our work time is during 8:00 am -5:30 pm ,from Monday to Friday (GMT+8 ).We will post your order within 24 hours (Except some special orders ,such as the handmade case). Maybe we are out of office during the weekend, so pls wait for our reply patiently. We will reply all your problems as quickly as we can. Thanks for your understanding. Engineered for professional eBay sellers!
