Digital Oscilloscope Portable Storage Tft Tester Multimeter 2mhz 5msps Dso112a

C $70.19

Shenzhen, China
Aug 14th

Open on mobile:
QR code

DSO112A Digital Oscilloscope Mini Storage Wave TFT Multimeter Tester 2MHz 5Msps Description DSO112A TFT Mini Digital Oscilloscope Touch Screen Portable USB Oscilloscope Interface 2MHz 5Msps Description: DSO112A is a pocket oscilloscope with color display and touch panel. What makes DSO112A distinguished among peers is its easy operations, which are all straightforward touching and scrolling. Almost everything is self-teaching. You would not get lost as you might do with other handheld scopes. Designed specifically for students and hobbyists, DSO112A is a great entrance level oscilloscope. With a size that fits right in your hand and pocket, DSO112A can do much more than you might think from its dimension. High sensitivity (2mV/Div), high accuracy, and low noises are highlights of DSO112A and make it a useful tool for small signals probing. TFT color LCD, 1200mAh Li-ion battery (included)... all these add great convenience in use. Features: 1.A pocket oscilloscope with color display and touch panel. 2.2MHz analog bandwidth and 5Msps Max. real-time sampling rate. 3.Unique rolling slow signal display, the display can be fully continuous signal, unlike SCAN mode will cause the signal display discontinuous. 4.Vertical sensitivity: 2mV/Div, with high accuracy and low noises. 5.Can save 24 groups of preset parameters, save and recall waveform conveniently. 6.Measuring frequency and Max./Min./Vpp/Avg. values of voltage. 7.Adds external triggering function, stronger signal capture ability. 8.PC upload waveform data. 9.Freeze at any time waveform display (HOLD function). 10.Square wave test signal comes 1000Hz/3.3V. 11.Firmware upgradable via Micro USB. 12.Battery/USB powered, built-in smart charger. Specifications: Analog Frequency Bandwidth: 0-2MHz Max. Real-time Sampling Rate: 5Msps Vertical Sensitivity: 2mV/Div-20V/Div Total 12 grades(by way of Progressive 1-2-5) Horizontal Time Base Range: 1s/Div-50s/Div 21 grades(by way of Progressive 1-2-5) Max. Input Voltage: 50Vpk (100Vpp) Max. Record Length: 512/1024 Optional Input Resistance: 1M ohm ADC Precision: 8 Bit Coupling Method: DC / AC Trigger Type: Auto, Normal, Single Trigger Edge: Rising / Falling Edge Trigger Source: Internal / External External Trigger Voltage: 0-15V Time cursors, can automatically calculate and display the time difference Voltage cursors can automatically calculate and display the voltage difference Display: TFT Color Display Power Supply: 3.7V 1200mAh Li-ion Battery(included) / USB Interface Dimension: 68 * 78 * 18mm / 2.7 * 3.1 * 0.7in Weight: 85g / 3.02oz Package Size: 17.5 * 10 * 3cm / 6.9 * 3.94 * 1.18in Package Weight: 201g / 7.09oz Package 1 List: 1 * DSO112A Touch Screen Oscilloscope with Battery 2 * MCX-clip Cables 1 * USB Cable Package 2 List: 1x DSO112A Touch Screen Oscilloscope with Battery 1x MCX-clip Cables 1x Bnc Conversion Line 1x P6020 1/10 20Mhz Probe 1x USB Cable About us 1.Payment We accept Paypal ONLY. 2.Shipping. 1).We ship to most of countries in the world. Item will be post to customer's ebay address within 1 working after payment arrive. 2).Item will be sent with tracking number when order value is over USD16. Or we'll ship order without tracking number. 3).Pls leave a note or send a message if any question. 3. Tax Import duties, taxes and charges are not included in the item price or shipping and handling. These charges ore the buyer's responsibility. 4. Return We understand that not every purchase is a good one for every custome Please note that we only accept returns within 30 days after delivery. a).If the item is defective/DOA (Dead on Arrival) we must be notified within 2 days of arrival, and a refund in full will be granted after item is sent back. b).Returns after 30 days will not be accepted. c).Please allow up to 3 business days for your item to be inspected and your return to be be processed. 5. Working Time We work from Monday to Friday. We'll reply message within 24 hours during working time and 48 hours during vacation. We'll do best to solve problem, don't worry.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DSO112A
MPN	WU0260/WU0259-91
Analog Frequency Bandwidth	0-2MHz
Max. Real-time Sampling Rate	5Msps
Max. Input Voltage	50Vpk (100Vpp)
Max. Record Length	512/1024 Optional
Input Resistance	1M ohm
ADC Precision	8 Bit
Coupling Method	DC / AC
Trigger Type	Auto, Normal, Single
Trigger Edge	Rising / Falling Edge
Display	TFT Color Display
Power Supply	3.7V 1200mAh Li-ion Battery(included) / USB Interface
Dimension	68 * 78 * 18mm / 2.7 * 3.1 * 0.7in
Brand	Unbranded
