Digital Oscilloscope Usb Storage Kits 2channel 100mhz Bandwidth Tft Lcd Screen

US $164.99

Loudi, Hunan, China
Jul 24th

Open on mobile:
QR code

Digital Oscilloscope USB Storage Kits 2Channel 100MHz Bandwidth TFT LCD Screen Features: Intelligent anti-burn, 1X can withstand up to 400V withstand voltage. 100MHz analog bandwidth @ 1GSa/s sampling rate(1X = 5MHz,10X = 100MHz). Fully fit 7 inch 800 * 480 resolution color TFT LCD display with bright colors and high contrast. Capacitive touching screen, the same as the touching mode of modern mobile tablet, is not a resistive touching screen with ancient nail operation. High measurement voltage range, 1X can measure 0~40V, 10X can measure 0~400V,100X can measure 0~4000V. Up to 12 parameters measurement:VPP, VP, Vmax, Vmin, Vavg, Vrms, Frequent, Duty+, Duty-, Time+, Time-, Period. Cursor measurement function, it is convenient to manually measure the period and frequency and voltage. Complete triggering function (single, normal, automatic). At any time, the waveform display (pause function) is frozen. Equipped with high efficiency One-button AUTO. One-button waveform storage and screenshot. Built-in 1GB storage space, can store up to 1000 screenshots + 1000 sets of waveform data. Powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc. Equipped with a USB interface, which can be connected to a computer to share its screenshots with the computer, which is convenient for secondary analysis. Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals. FFT display function, can analyze the spectral characteristics of the signal. Built in 6000mAh rechargeable lithium battery, fully charged for 4 hours of continuous use at the highest screen brightness. Memory compression technology, waveform refresh screen does not flicker. Screen brightness adjustment. Background brightness adjustment. Ultra thin, easy to carry. Specifications: Material: ABS Color: black+white Analog band width: 100MHz * 2 Number of channels: 2 channels Maximum real time sampling rate: 1GSa/s Vertical sensitivity: 50 mV/div~500 V/div Horizontal time base range: 50S/div~10nS/div Maximum test voltage: 40V (1X probe), 400V (10X probe) Storage depth: 240Kbit Input resistance: 1M ADC accuracy: 8bits Coupling mode: AC/DC Trigger mode: Single, Normal, Auto Trigger edge: Rising edge/Falling edge External trigger voltage: 0~40 V Display: 7 inch - 800*480 Operating: Capacitive touching screen + gesture Extension ports: USB picture export Power supply: 1 * lithium battery, 6000mAh (included) Item size: 184 * 124 * 50mm / 7.2 * 4.9 * 2.0in Package size: 230 * 150 * 60mm / 9.1 * 5.9 * 2.4in Package weight: 1000g / 2.2lb Package: 1 * 1013D Oscilloscope Host 2 * Matching 100MHz Probe (1X and 10X) 1 * USB Data Line 1 * User Manual (English) For any question please contact us

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Number of Channels	2
One key automatic	Support
Model	1013D
Real Time Sampling Rate	1GSa/S
Modified Item	No
Record Length	Storage depth: 240Kbit
Country/Region of Manufacture	China
Sampling rate	500M
Custom Bundle	No
Single trigger	Support
Oscilloscope Type	Digital Oscilloscope
Analog brandwidth	110M
Time base range	5ns-10s
Digital Channels	2
Band Width	100-349MHz
Display resolution	800*480 Pixels
Brand	Unbranded
Features	Handheld/ Portable
Trigger mode	Auto/normal/single
Display Size	7 Inches & Above
Maximum Bandwidth	100 MHz
DIY Supplies	ELECTRICAL
Battery	1 * lithium battery,3000mAh
MPN	0489706257
Vertical sensetivity	20mV/div-100V/div
Input resistance	1M
Channel coupling	AC/DC
Waveform measurement	14 types
Digital Oscilloscope Resolution	8-bit
