Digital Pressure Switch,0-16bar(232psi) 240v G1/4 0.5% Water Pump Air Compressor

US $260

Shanghai, China
Jun 10th

Open on mobile:
QR code

OEM Service; Customized Service; Best Price and High Quality; Our Company Was Founded in 1994. CE Certificate; ISO9001; Explosion-proof Certificate for Pressure and Level Sensor; CMC for Load Cell Sensor; CMC for Pressure and Pull Pressure Sensor. Specifications: Pressure Range: 0 to 16bar; Power Supply: 240VAC; Pressure Connection: G1/4; Accuracy: Better than 0.5%FS; Overload Capacity: 200%; Setting Range: Anyone within the full measurement range; Output: ON/OFF signal by relay; Relay Capacity: 240V 5A; Frequency: 5 times/second; Temperature: -20—85C; Material: Compatible with 316L stainless steel; Protection: Reverse polarity and short circuit protection; Wires Connection: Power(red and blue),Output(black and white); Weight: 0.27KG; It can save all setting automatically if the power failure. Applications: 1, Water treatment system; 2, Medical treatment; 3, Agriculture machine; 4, Water pump and air compressor; 5, Mechanical and electronic automation; 6, Pneumatic and hydraulic system; 7, Engineering equipment; 8, Test equipment. Setting Function: 1, Power-on Self-test; 2, Check pressure automatically; 3, Over-pressure checking; 4, Setting delay time for controlling; 5, Setting password for parameter protection. Characters: 1, Setting pressure limits by your requirements; 2, Clearly indicating by 4-ways LED digital value; 3, Relay signal output to avoid the device operate invalidly frequently; 4, Have longer life time by comparison with traditional mechanism switch; 5, Nice controlling accuracy and fast response; 6, Anti-vibration,strong anti-jamming ability; 7, Easy to connect the wires and install; 8, Display and control the pressure in time; 9, Can set upper/lower limit value and set alarm point. Package Contents: 1 x Digital Pressure Switch; 1 x Fully English Manual; 1 x Very professional service. Shipping: 1, Will ship out the goods within 1 business day upon receipt of the payment; 2, e-Packet with tracking number(will take 7-12 working days) to United States,Russian Federation,United Kingdom,Australia; 3, China Post Air Mail with tracking number(will take 20-30 working days) to all over the world; (Note: sometimes the delay will be taken place on account of the weekends,the bad weather,holiday and other reason.) 4, The items can be shipped out through fast way DHL,FedEx,UPS etc if pay the extra freight,the cost of post air mail will be deducted from the fast mode of transportation,contact with us if have any question. Have stocks for following parameters: 0-16bar; 12VDC; G1/4; 0-16bar; 12VDC; NPT1/4; 0-16bar; 240VAC; NPT1/4; 0-16bar; 240VAC; G1/2; 0-16bar; 240VAC; G1/4; Two Relay Output with 0-16bar;240VAC;G1/4; Air Negative Vacuum with 0 to -0.1Mpa;240VAC;G1/4. Please see in our store: http://stores.ebay.com/Ahead-Instruments-and-Electronics/Digital-Pressure-Switch-/_i.html?_fsub=4620585013&_sid=1086435763&_trksid=p4634.c0.m322
