DIY DS1302 Rotating LED Electronic Digital Clock Kit 51 SCM Learning Board 5V xp Description Description: Size: 81 mm x 81 mm x 1.6 mm PCB thickness: 1.6 mm Materials: FR4 military level PCB color: blue DigitalTube display: red Power supply voltage: miniUSB, external connection 5V ,3V button battery for clock chip on the board of the standby power supply Function: a. Electronic clock function. Four digital tube display time function. Every second, digital tube, two points on a flashing, at the same time, the casing outside the clock LED will take turns to light up a take turns bright finish a circle represents the clock through a minute b. Date display. Through the key switch, you can see the default date. Specific look at the following keys function description c. Alarm function. Through the button switch, you can set the alarm clock function. When to set the alarm time, buzzer sounds, if not, manually turn off the buzzer will continue to ring for 10 minutes. Specific look at the following keys function description d. Burning function. The reserved buffer program interface, can change to the circuit board to do procedure, easy to operate e. Real time clock function. Tone after a preset time, even if the power lost, again after power on, no need to set a time f. Temperature display function. Under the time display mode, press PLUS, can display the current temperature g. Many mode display function. Outer LED display has four modes, can cooperate to add key implementation, through the model key Mode 0: is also the default display mode, all the 1-12 hours red digital tube light, when the clock through a second, is the green digital tube is take turns to light up a. Mode 1: as the clock through a second, outer ring LED lit one by one, that is 60 seconds, outer ring all the LED light. The next minute, all leds light up, and through the clock for a second, put out one by one. And the next minute, leds light up one by one again, so alternates. Mode 2: when the clock through a second, outer ring take turns to light up a LED. The first seconds, only the first LED light, 2 seconds only the second LED light. Mode 3: when the clock through a second, outer LED turns off a. The first seconds, only the first LED out, only the second LED out 2 seconds Key Function: PLUS key, for years, months, days, hours, minutes, seconds add operation. According to the numerical sum 1 at a time MODE key, can be in display clock, switch to the year, month, day, hours, minutes, alarm clock, the adjustment of outer ring LED display state. To use add key to the year, month, day, hours, minutes, seconds, and display mode to adjust RST key, press the reset button, then the MCU reset Some infomation here: Data sheet Schematic Notice: The version is update to V1.2, just the logo change,all the function doesn't change. Package included: 1 x Rotation LED Electronic Clock Kit Documents: Download Link Payment : We accept PayPal ONLY! It is agreed that the winning bidder would enter in a legally biding contract for purchasing the above item after won the auction. Shipping&handing: Item will not ship until payment has been received in full. All items ship from Hong Kong directly. Normally it takes 7-14 working days to the most part of the world. All shipments will be made within 48 hour (Not include weekend and holiday) after payment has been confirmed departing form Hong Kong. Insurance: Item Insurance (Optional) : $:2 / ?:1 Shipping & Handling & Insurance Fee Insurance fee (Optional). For shipping without insurance, seller will not bare any responsibility for parcel lost, damaged, or stolen mail during delivery. Please PAY FOR INSURANCE to avoid these situation. Insurance fee (Required). The buyer must pay for the insurance fee and no exception
