Diy Kit For Soldering Smd Circuit Board Led Electronic Project For Soldering

US $8.10

suzhou, China
Jul 5th

Open on mobile:
QR code

Product Description DIY Kit For Soldering SMD Circuit Board LED Electronic Project For Soldering Item Details: 100% brand new and high quality Made of high quality material, durable and practical to use Surface-Mount Soldering Practice Board with Rotating LED Circuit This project is aimed at those new to soldering surface-mount components. It allows you to hone your skills in soldering resistors, capacitors, diodes and LEDs, transistors and IC chips. The kit includes an 85x54mm printed circuit board (PCB) and 126 surface-mount (SMD) electronic components. A simple rotating light wheel project in the central section of the PCB gives you the chance to put your newly learned skills to the test! The areas on the left and right sides of the PCB are for practicing your soldering skills, while the central area has a functional electronics project with sequentially flashing coloured LEDs. In the practice zones, you can improve your expertise at surface-mount soldering with 78 components in four standard sizes ('1206', '0805', '0603' and '0402'). The board is compatible with surface mount soldering techniques using a soldering iron and fine solder wire, or solder paste and a hot-air rework station, or even with a professional reflow oven. If you haven't had any experience with soldering surface-mount components before, you can find many helpful instructional videos online. Each column of practice zone components is connected to test pads at the bottom of the board, so that you can use a multimeter to check that everything is well connected. The project area of the board will, if soldered correctly, reward you with a spinning display of 15 coloured LEDs! There are 48 components in the project. Once you have finished soldering, simply connect a battery or other DC voltage of between 4V and 12V (not supplied) to the power input pads to launch the rotating light display! Please note that LED colour may vary from that pictured. Package Contents: 1*Circuit Board Electronics Project DIY Kit Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours. On Jul-05-21 at 14:40:16 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Package Contents	1*Circuit Board Electronics Project DIY Kit
MPN	Does Not Apply
Type	Circuit Board Electronics Project
UPC	Does not apply
