Dla106 Digital Logic Analyzer 6 Channel For Pic / Avr / Arm / Arduino / Psoc

US $45.99

NT, Hong Kong
Feb 26th

Open on mobile:
QR code

DLA106 Digital Logic Analyzer A logic analyzer is an electronic instrument that captures and displays multiple signals from a digital system or digital circuit. A logic analyzer may convert the captured data into timing diagrams, protocol decodes, state machine traces, assembly language, or may correlate assembly with source-level software. Logic Analyzers have advanced triggering capabilities, and are useful when a user needs to see the timing relationships between many signals in a digital system. Many digital designs, including those of ICs, are simulated to detect defects before the unit is constructed. The simulation usually provides logic analysis displays. Often, complex discrete logic is verified by simulating inputs and testing outputs using boundary scan. Logic analyzers can uncover hardware defects that are not found in simulation. These problems are typically too difficult to model in simulation, or too time consuming to simulate and often cross multiple clock domains. Field-programmable gate arrays have become a common measurement point for logic analyzers. And it also used for debug the logic circuit. DLA106 using AVR processor and includes a 2.6" 128x64 graphic display with 6 channel. it is easy to used simple , reliable , inexpensive for MCU testing such as PSoC, ARM , AVR , PIC , Arduino etc. [Power] DC5v IN, User can connected USB cable for Power or VCC to MCU Power for 5v [Magnify] (X1) (X1/2) (X1/4) [Sampling Time] 5uS?10uS?20uS?50uS?100uS?200uS?500uS?1mS?2mS?5mS?10mS?20mS [RUN] Click a RUN to START/STOP the capture of signal , if no signal, the screen will show [READY]. [Sampling frequency] 5?S ~ 20mS, pre-trigger 128 / post trigger 640 points. [6Ch. Display] By · A / B 2 one of the cursor, can be time measurement of (between A-B) and (between the trigger point -A cursor). Power DC : DC5v Maximum real-time sampling time: 20mS Sampling buffer depth : 640d Analog bandwidth : 0 - 100KHz Magnify : (X1) (X1/2) (X1/4) Dimenson : 74 x 62 x 21mm Package include:: 1) DLA106 1pcs 2) Test jumper 10pcs 3) USB cable 1pcs Contact Us :: Website : www.wide.hk Email : info@wide.hk / widehk.info@gmail.com Feedback & Case/Dispute :: When you get the item(s) your bought, if you satisfied or our services, please leave us Positive Feedback & 5 Star DSR as the following image. If you have any problems, please contact with us in advance, We can give you response within 48 hours when we get your message, we'll try our best to give you the better solution for you. ** Please don't open Case / Dispute or leave Negative / Neutral to us directly, or you'll assume the responsibility/result. Shipping Police / Time :: Related Track Website for items status : http://www.17track.net/index_en.shtml 1. Item will be sent out within 96 hours(except weekend and holidays) after we receive the payment. Items shipped from Hong Kong Post air mail with tracking number. 2. It is estimated that package will arrive in 10-25 working days. (holidays and weekends are not included) to most countries! If you do not get the item(s) after 35 working days please email us we will Refund or Reship. 3. Since air mail will takes long time for delivery, if you want items urgently, you could contact us to ask shipping cost of Express mail. 4. We are not responsible for any custom duty or import . 5. We only ship the item to the address listed in your paypal payment. Please make sure your shipping address is correct. 6. If you have any request (e.g. change address), please put a note on paypal. Country Estimate Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-30 >30 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-30 >35 United States Rate (item arrived) 9% 50% 21% 13% 7% United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Australia Rate (item arrived) 23% 50% 13% 8% 6% France Rate (item arrived) 1.5% 20.5% 45% 23% 10% Germany Rate (item arrived) 5.5% 25% 35% 19% 15.5% Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Spain /Italy Rate (item arrived) 1.5% 25% 50% 14% 9.5%

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Digital
Model	Logic Analyzer
