Dormer E653 High-speed Steel Combination Drill And Pipe Tap, Npt 1"-11.5 Thread

US $220

Boaz, Alabama, United States
Jun 22nd

Open on mobile:
QR code

Dormer E653 High-Speed Steel Combination Drill and Pipe Tap, NPT, Uncoated (Bright) Finish, Round Shank With Square End, 1"-11.5 Thread Size The Dormer E653 uncoated, high-speed steel spiral flute tap and drill combination has a round shank with a square end and a modified bottoming chamfer, and is used to drill holes and create NPT (National Pipe Taper) right-hand threads in a range of materials. The tool drills and threads holes in one operation. Its 27-degree spiral flutes pull chips back from the tip of the tool, up and out of the hole to prevent clogging, making it suitable for use in through holes (extending through the workpiece). The modified bottoming chamfer has additional length to reduce chip load, add tool life in difficult to machine materials, and permit higher tapping speeds. Right-hand threads are designed to tighten when a head or nut is rotated clockwise (the most common threading direction). High-speed steel (HSS) is a common general-purpose steel for cutting tools and is compatible with a variety of materials. With no coating or surface treatment, this uncoated tool can be used on a broad range of materials and provides an economical alternative to coated tools. The round shank with square end helps to minimize rotation in the tool holder. This tool can be used in machines, such as drill presses or lathes, or with hand tools such as tap wrenches. In the Dormer E653 series all tools have two flutes and modified bottoming chamfers. This tool conforms to ANSI standards and can drill and create threads to a depth one-and-a-half times its diameter. It is suitable for normal pipe thread tolerance. Combination drill and tap tools are designed to create holes and cut threads in one pass. Taps produce internal threads in previously formed holes and can be used in machines (such as drill presses) or with hand tools. Common types of taps include hand taps, spiral point taps, spiral flute taps, thread forming taps, and pipe taps. Hand taps (straight-flute taps) collect chips in the straight flutes of the tool; spiral point taps push chips through holes ahead of the tool; and spiral flute taps pull chips back from the tip of the tool, up and out the hole. Thread forming taps, also known as cold forming taps, press rather than cut to create threads in a drilled hole, and no chips are created. Pipe taps create threads in pipes and pipe fittings. Each thread type designates a thread profile and each type is identified with an abbreviation. In the U.S. and Canada, the Unified Thread Standard is the dominant thread type, including UNC (Unified Coarse), UNF (Unified Fine), and NPT (National Pipe Taper) threads, among others. Seller Notes: I only ship to the connected 48 states. I do not ship to APO's or P.O. Boxes. Please do not ask to ship anywhere else it will not happen. WE ONLY SHIP TO PAYPAL CONFIRMED ADDRESSES!!! If you have a P.O. Box make sure you change your address in paypal before purchasing so that we get the address you want it shipped to. We cannot change ship to address after the fact or Seller Protection is void. Thank you for understanding. ***PLEASE READ BEFORE PURCHASING*** This item was acquired through a bulk load we have purchased of random merchandise. We do not know the history of this item. Please view pictures closely, you are buying as pictured. We have tried to test it to our best ability but are not going to guarantee something is not missing. Items that require bolts may be missing some bolts. Items with small pieces may be missing some small pieces. Items that use electricity may stop working at any time. If this item has a buy it now price it will be on it . If we are accepting offers there will be an option on the listing. If we start it at $.99 on auction it will sell to the highest bidder and does not have a buy it now price. We now list everything as used no matter what the condition . It may look new and be sealed but it is always listed as used unless stated otherwise . If we make a mistake we will try our best to rationally solve the problem . If you have any questions or concerns feel free to send us a message. Check out my other items! Be sure to add me to your favorites list! Have a great day and thanks for checking out our listing!!!
