Double Bts7960b Dc 43a High-power Stepper Motor Driver H-bridge Pwm Module

US $14.99

Shanghai, China
Jul 17th

Open on mobile:
QR code

Double BTS7960 43A High-power Motor Driver H-bridge PWM module Welcome to Our Store!!! Description BTS7960 DC 43A is a fully integrated high current H-bridge module for motor drive applications. Interfacing to a microcontroller is made easy by the integrated driver IC which features logic level inputs, diagnosis with current sense, slew rate adjustment, dead time generation and protection against overtemperature, overvoltage, under voltage, overcurrent and short circuit. The BTS7960 provides a cost optimized solution for protected high current PWM motor drives with very low board space consumption. Weight :- 66g. Input voltage :- 6V-27V. Maximum current :- 43A. Input level :- 3.3V-5V. Control mode :- PWM or level. Duty cycle :- 0 to 100%. Current conditioning output :- Yes. Size :- 50mmx40mm/1.97x1.58 (approx.). Specification Double BTS7960 large current (43A) H-bridge motor driver. 5V isolate with MCU, affectively protect MCU. 5V power indicator on board. Voltage indication of motor driver output end. Can solder heat sink. Just need four lines from MCU to BTS7960 driver Module (PWM1, PWM2, GND and 5V). Two heat flow passing through an error signal output. Isolated chip 5V power supply (can be shared with the MCU 5V) and can also use the on board 5V power supply. Shipping/Payment/Returns We ship to your eBay address. Items will be dispatched within 1 - 10 days after the payment due to the global pandemic situation but we are trying our best to dispatch as soon as possible. We accept PayPal payments only. We accept returns. Customer service Our goal is to provide high quality products for a good competitive value, backed by excellent customer service. Contat Us Feel free to contact us if you have any questions. Your positive feedback is highly appreciated. Please let us know before leaving any negative feedback. Please give us the opportunity to resolve any problem. Please contact us through eBay. We will be happy to assist you. Thank you!!!!!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	43A
MPN	Does Not Apply
Modified Item	No
Brand	Unbranded/Generic
Input Voltage	6V - 27V
UPC	Does not apply
