Douglas Lighting Controls - Dlp2-16r16d-sm

US $2,588.23

Whitmore Lake, Michigan, United States
Jul 12th

Open on mobile:
QR code

Special Relay Panels - Dimmable 2.1.1 Relays Lighting control relays shall be mechanically latching and shall come complete with a manual ON/OFF switch. The mechanical switch shall continuously display the true state of the relay’s internal contacts. • Single pole relays shall be rated and UL/CSA listed for 120, 277and 347 VAC lighting loads at 30A General Use. Use Panasonic WR-6161K-84. 2.1.2 The single pole relays shall have a label indicating the short circuit current rating of 18,000A @277VAC. 2.1.3 Each lighting control relay shall be capable of controlling incandescent, fluorescent, electronic ballast, LED, and H.I.D lighting loads. 2.1.4 Lighting control relays shall include captive screw terminals for both the line voltage and the low voltage connections. Switching the relay shall be accomplished with ONE signal wire and a common return. The signal wire shall be able to signal ON and OFF and shall carry status current that indicates if the relay is ON or OFF. 2.2 Pre-assembled Relay Panels: LitePakTM 2 Series 2.2.1 Where indicated on the drawings, provide a factory pre-assembled relay panel. The panel shall be for surface or flush installation, with a hinged door assembly as required. 2.2.2 The panel shall be a NEMA 4 surface mount enclosure, with a hinged door assembly. 2.2.3 The panel shall be factory pre-assembled; ETL certified to UL/CSA standards, with capacities for 1 pole or 2 pole relays. 2.2.4 Panel shall include the following pre-assembled and pre-wired: • Suitable divider separating class 1 and class 2 compartments • Control transformer, UL/CSA approved for class 2 circuits, Douglas Lighting Controls Cat. No. WR-4075-120/277 or WR-4075-120/347. • External control devices as required • A digital Central Panel shall have 8 or 16 relays • 0, 8, or 16 independent 0-10V dimming channels • a touchscreen interface • The digital Central Panel shall connect to expansion panels and peripheral devices (Switches and Sensors) using a common, solid #18/2 wire network • Expansion panels shall have 8 or 16 relays and 0, 8, or 16 independent 0-10V dimming channels. • The Central Panel and expansion panels shall have a maximum combination limit of 48 relays.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Application	Light Control
Box Shape	Rectangular
Brand	Douglas Lighting Controls
