Drive Lithium Charger Power 5a Step-down Module With Voltmeter Ammeter Cc Cv Led

US $6.13

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

???? 1 ???? 1 ???? 1 ???? 1 ???? 1 ???? 1 ???? 2 ?|aЂ“a°??&a circ;?ao?§a?aЂ&ti lde;??a?a? 6 5A CC CV LED Drive Lithium Charger Power Step-down Module With Voltmeter Ammeter Description: Note: 1.When you use the product, the module inputs and outputs to be isolated from ground. 2.USB output voltage is consistent with the module, not a fixed 5V output. When charging for digital equipment, make sure USB output voltage is 5V. 3.Some customers report: “The module can not adjust the output voltage is always equal to the input voltage.” When you encounter this problem, please counterclockwise rotation of the “voltage potentiometer” 10 laps or more, then use the module you can adjust the output voltage. Because the factory default output voltage of about 20V. Specifications 1.Input voltage range:5-36VDC 2.Output voltage range:1.25-32VDC adjustable 3.Output current: 0-5A 4.Output power: 75W 5.High efficiency up to 96% 6.Built in thermal shutdown function 7.Built in current limit function 8.Built in output short protection function 9.Input reverse polarity protection: None (if required, high current diode in series with the input). 10.L x W x H =68.2x38.8x15mm Application 1.Use as a step-down modules with overcurrent protection Usage: (1) Adjust the right button so that “OUT” LED lighted, Digital meter shows the value of output voltage ,adjust the “voltage potentiometer” so that the output voltage reaches the value you want. (2) Adjust the right button so that Digital meter shows the value of output current;Wire shorted output terminal, then adjust the “current potentiometer” so that the output current reaches a predetermined overcurrent protection value. (For example, the Digital meter displays the current value of 4A, then you can use the module to a maximum current of 4A) (3) Connected to the load. 2.Use as a battery charger Usage: (1) Make sure you need to charge the battery float voltage and charging current; (if lithium parameters 3.7V/2200mAh, then the float voltage is 4.2V, the maximum charging current 1C, ie 2200mA) (2)Under no-load conditions, adjust the “Voltage potentiometer” so that the output voltage reaches the float voltage; (if to 3.7V rechargeable lithium battery, the output voltage can be adjusted to 4.2V) (3)Adjust the right button so that Digital meter shows the value of output current;Wire shorted output terminal, then adjust the “current potentiometer” so that the output current reaches a predetermined Charging current value. (4)Charge turn lamp current factory default is 0.1 times the charging current; (Battery during charging current is gradually reduced, if the charge current setting is 1A, then when the charge current is less than 0.1A, blue lights turned off, the green light is on, which means that the battery is fully charged) (5)connected to the battery charge. (1,2,3,4 steps as: Output is unloaded, do not connect the battery) 3.Use as a LED constant current driver module Usage: (1)Adjust the “voltage potentiometer” so that the output voltage reaches the value you want. (2)Adjust the right button so that Digital meter shows the value of output current;Wire shorted output terminal, then adjust the “current potentiometer” so that the output current reaches a predetermined LED operating current. (3)Connect LED, work. (1,2 steps as: Output is unloaded, do not connect LED) Voltmeter and ammeter calibration method: Module with manual calibration function can correct display precision voltage and current, if you think the current voltage and current accuracy to meet the requirements, do not perform the following operations. (1) Output voltage calibration steps Step 1, adjust the right button so that “OUT” LED lighted, Digital meter shows the value of output voltage; Press the right button for more than 2 seconds, release, Digital meter and “OUT” LED flashes in synchronization so that you enter the output voltage calibration mode. Step 2, press the right button (normal speed), the voltage value is adding up a unit; Press the left button, minus a unit; Due to a unit is less than 0.1V, the minimum voltage display to 0.1V, so you need to continuously press 1-5 times to see the voltmeter change 0.1V, how many times voltmeter change 0.1V by pressing the key, depending on the current display voltage, the higher the voltage, the fewer the number of press. Step 3, press the right button for more than 2 seconds, release, to exit the output voltage calibration mode. All parameters set to automatically power down to save. (2) Input voltage calibration steps Step 1, adjust the right button so that “IN” LED lighted, Digital meter shows the value of input voltage; press the right button for more than 2 seconds, release, Digital meter and “IN” LED flashes in synchronization so that you enter the input voltage calibration mode. Steps 2 and 3, consistent with the output voltage calibration method. (3)Output current calibration steps Step 1, adjust the right button so that Digital meter shows the value of output Current. Press the right button for more than 2 seconds, release, Digital meter flashes in synchronization so that you enter the output current calibration mode. Step 2,Connected to the load, ammeter in series, adjust the right and left button to change the display of digital meter, so that is consistent with the ammeter display . Note: Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you! Package includes: 5A CC CV LED Drive Lithium Charger Power Step-down Module x 1 Payment: We accept payment through Paypal ONLY. If you do not have Paypal account, please registered with (http://www.paypal.com) Payment must be received within 5 days after auctions ended. Please do not bid if you are not intending to buy. Unpaid dispute will be filed to ebay for the non payable bidders. Shipping and handling:: Return Policy: We are not responsible for custom duty or import tax. We will leave POSITIVE FEEDBACK after receiving the payment. Please contact us if your are not satisfied with the item after receive it. We could offer refund, and refund request is available only requests within a week after parcel received & returning the item as the same condition as received. We offer 100% refund if the item is broken before arrival, all you need to do is sending us the clear pictures to show it is broken. Defective situation must be noticed within 7 days after delivery. All emails will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your email,and we will reply to you as soon as possible. All items sold by us are being described to the best of our abilities, as accurate as possible, and with utmost conscientiousness on our part.However, to avoid any potential oversights, I respectfully request your assistance in helping us to make this a mutually satisfactory transaction by Thoroughly reviewing item description and photos, and asking all questions Prior To Bidding. Please Note that size and color representation are subject to manufacturing variance and may not be exact. Also note that monitor settings may vary from computer to computer and may distort actual colors. Please read these terms thoroughly before placing your bid. Feedback: We will automatically leave a positive feedback to everyone who has complete the transaction and leave us positive feedback. Please do not forget to give us Five Stars on all of the Detailed Seller Ratings. Thanks! In the unlikely event you are not satisfied with the transaction, please contact us before you submit your evaluation. We believe that everything could be solved by communication. 1.in order to provide you the best service*****,please treat the transaction fairly.*feedback is simply what we pursue. 2.Please Do contact us first to get a better solution before you would leave a *neutral or *negative feedback 3.We strive for 5-star service by stating upfront our policies, our shipping rate& our shipping frequency. if you were pleased with this transaction, please respond with all 5 stars! if you are not pleased, simply let me know via e-mail rather than leave low score, and I'll work to make it that way 4.Please email me through 'MY MESSAGES' or "Ask Seller Questions" if you have any question about our listing or your purchase Contact us: We are in Shenzhen of Pearl River Delta which is developed place with economy and Trade We are a profession trade company. There are about 16000 kinds of products in my company, Our products include consumer electronics, Nail Art Tools, Clothes and shoes, cell phone accessories, computers accessories, car accessories, Motorcycle accession, toys & hobbies, jewelry, baby accessories other useful electronics items and etc If you have any problems, we are very glad to help you. We rare handling large volume emails every day. Please allow us to reply your email within 24hrs For the functional products in our shop (such as: Chargers, Data cables), which function is the same as description, but the actual color and shape may looks a little different from pictures because of the technical improvement and actual stock state. Please be advised before you bid. Copyright(c)2005 wangdecheng9898 All Rights Reserved On Dec-30-14 at 22:52:54 PST, seller added the following information:

Condition:

New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...

Brand

Unbranded/Generic
