Drok? L298n Motor Drive Controller Board Dual H-bridge Dc Motor Driver Chip

US $240

USA, United States
Jun 16th

Open on mobile:
QR code

Best Selling Stuff ABOUT US Feedback Other items NEWSLETTER DROK? L298N Motor Drive Controller Board Dual H-bridge DC Motor Driver Chip DC-DC 5-30V Regulator WIFI Car Drive Module with 2A Peak Current Can Drive 4 DC Motors/ 2 Stepper Motors PRODUCT DESCRIPTION Small size (90 * 55 * 33mm), easy to install. The module integrates 2 L298N chip, can drive 4 DC motors or 2 stepper motors. Large capacity filter capacitance, afterflow protection diode, more stable and reliable. It integrates LM2596 DC-DC voltage regulator chip (which can output 5V, the battery can up to 2A). Supports 3.3V MCU ARM control, can easily control the speed and direction of DC motor. FEATURES Product Description: This dual L298N driver module, using ST's L298N new original chip, and high stability SMT process, with high-quality electrolytic capacitors to make the circuit work stably. It can directly drive two 3-30V DC motor. and it provides a 5V output interface (the min input is 6V) to power for 5V single-chip circuit (low ripple factor). It also supports 3.3V MCU ARM control, you can easily control the speed and direction of DC motor, and control the 2-phase stepper motor, 5-wire 4-phase stepper motor. Product Parameters: Driver Chip: L298N dual H-bridge DC motor driver chip Power Supply of Driving Terminal: + 5V ~ + 30V (the range is +6V?+30V if taking Internal power) Peak Current of the Driving Part: 2A Operating Current of Logical Part: 0 ~ 36mA Control Signal Input Voltage (IN1 IN2 IN3 IN4): ????????????? ??Low level: -0.3V?Vin?1.5V ???????????? ??????? ??High level:2.3V?Vin?Vss Enable Signal Input Voltage (ENA ENB): ???????????? ???????? ?Low level:-0.3?Vin?1.5V (control signal is invalid) ???????????? ???????? ?High level:2.3V?Vin?Vss (control signal is active) Max Power Consumption:20W(when the temperature T = 75??) Storage Temperature:-25???~ + 130?? Drive Board Size:90*55*33mm(with fixed copper pillar and heat sink height) Other Expansion:control direction indicator, logical part board internal taking power interface. MORE INFO Manufacturer: DROK Shipping Weight: 20 Product Dimensions: Width: 3.50 Length: 5.50 Height: 1.90 Shipping Info -Even though eBay only allows us to enter three different shipping methods, we use a wide variety of shipping methods in order to best serve all of our customers. So don't look at the exact name of the shipping method, but look at the estimated delivery date, and choose based on that :) -All of our stock is located in the United States. -Most orders will ship out within one business day. 30 Days Return & Refund Policy -All items can be returned for a full refund within 30 days from purchase. -Please understand that due to our logistics solution we normally can't send out replacements. We'll send you a full refund though which you can then use to purchase the item again. -In case of buyer remorse the customer is responsible for return shipping. -If the item is damaged, not as described, etc., we will happily provide a prepaid shipping label so you can return the item at no cost to you. -Make sure to keep the packaging of the item until you're sure you don't have to return the item. Only returns with all the original packaging and accessories can be accepted. Satisfaction Guaranteed -We are super proud of our high feedback rate, and work hard every day to keep it that way. If for any reason you're not satisfied with your order, please let us know and we'll do our best to make it right. -If you know of any way we can improve our service, do please let us know :)
