Druck Ups Ii 4-20 Ma Smart Loop Calibrator

US $420.00

Miami, Florida, United States
Jan 29th

Open on mobile:
QR code

Up for sale: One (1) Brand new 4-20mA Calibrator made by Druck (GE Sensing dept.) Calibrator has been taken out to take a couple of pictures. UPS II Smart Loop Calibrator for Milliamps The UPS-II loop calibrator is an advanced handheld process calibrator tool. It can power (24 VDC) and read 2-wire transmitters to perform field calibrations. Output currents are adjustable to a resolution of 10 microamps in both source and transmitter simulation. Sources and reads milliamps Powers and reads 2-wire transmitters Reads and simulates DP transmitters in % of flow Auto-ramp cycling for endurance tests Auto-stepping for hands-free calibration Fixed calibration currents Fixed currents for valve stroking Output Range 0 to 21.00 mA Input Range 0 to 21.00 mA Accuracy 0.05% of range Resolution 10 microamps Temperature Effect 0.0015% /°F (0.003% /°C) Internal Loop-Power 24 VDC stabilized External Loop-Power 56 VDC maximum Measurement Input 12 O including fuse Drive Capability 900 O Operating Temperature 15°F to 120°F (-10°C to 50°C) Battery Life Sources 12 mA: 13 hours Measures: 64 hours Batteries 4x 1.5V AA Batteries Loop Mismatch Flashes "loop" Low Battery Flashes "lobat" Over range Flashes "EEEE" Reversed Polarity Flashes "pol" Housing High impact ABS Size 3 in x 5 in x 0.83 in (77 mm x 124 mm x 21 mm) Weight 9 oz (285 g) including batteries Fixed Steps The calibrator can source or simulate fixed calibration currents to test or calibrate receivers and to stroke valves. Different current levels are available from the menu. 4 to 20 mA linear 4, 8, 12, 16, 20 mA 0 to 20 mA linear 0, 5, 10, 15, 20 mA 4 to 20 mA sq.rt (flow) 4, 5, 8, 13, 20 mA 0 to 20 mA sq.rt (flow) 0, 1.25, 5, 11.25, 20 mA 4 to 20 mA 3.8, 4, 4.2, 12, 19, 20, 21 mA Output currents can be changed manually or automatically. The time between steps is 10 seconds in the auto-stepping mode. In the valve mode, auto-stepping will be: 3.8, 4, 4.2 or 19, 20, 21 mA Ramping The calibrator can source or simulate with high resolution a continuous up/down cycle between 4 and 20 mA or 0 and 20 mA. The travel time between limits is 60 seconds. Reading in Percentage The calibrator can display readings in percentage of a 4 to 20 mA or 0 to 20 mA span and can also read or simulate dP-transmitters directly in percentage of flow.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Druck
MPN	Druck UPS-II 4-20 mA Loop Calibrator
Model	UPS-II
