Dse Deep Sea Electronics Dse7310 Auto Start Control Module 7310 Heated 7310-32

US $2100

Forest Grove, Oregon, United States
Jun 8th

Open on mobile:
QR code

Deep Sea Electronics DSE7310 Auto Start Control Module The DSE7310 is a feature packed Auto Start Control Module designed to control single diesel or gas gen-set applications. OVERALL SIZE - 240 mm x 181 mm x 42 mm (9.4” x 6.8” x 1.6”) PANEL CUTOUT SIZE - 220 mm x 160 mm (8.7" x 6.3") MAXIMUM PANEL THICKNESS - 8.0 mm (0.3”) WEIGHT - 0.86kg Key Features and Benefits: Heated display option 3-phase generator sensing Power monitoring (kW h, kV Ar, kV Ah, kV Ar h) Remote communications (RS232, RS485, Ethernet) Configurable inputs/outputs (9/8) CAN and magnetic pick-up sensing Fuel usage monitor and low level alarms Tier 4 CAN engine support True dual mutual standby with load balancing timer Configurable display languages Power save mode Integral PLC editor Flexible sender inputs DSE Configuration Suite PC Software Configurable event log (250) Load switching, load shedding & dummy load outputs Ensures the display continues to operate in extreme cold weather conditions Provides true generator sensing Provides clear accurate power measurement information Provides secure and simple off site monitoring. All ports are continuously active Provides multiple installation options Makes the module ideal for standard and electronic engine applications Tracks the amount of fuel being used and sounds an alarm if over/under fuel use is detected Ensures the control module can be used with the latest in modern electronic engine technology Enables two set systems to be configured to allow for redundancy or balancing run hours Ensures the control module is suitable for worldwide use Reduces the power usage within system batteries Ensures additional applications are easily integrated into the system Allows alternative sender types to be selected using one input Provides complete user-friendly configuration and easy-to-use high-level system control & monitoring Provides access to historical alarms and operational status Allows load options and dummy load requirements to be independently controlled Additional Features: Customisable status screens Multiple date & time scheduler Charge alternator failure alarm CAN engine manual speed control Modem diagnostic display screens Remote display support (max 3 units) Manual fuel pump control Engine exerciser kW & kV Ar overload protection Reverse power (kW & kV Ar) protection Unbalanced load protection USB connectivity Backed-up real time clock Configurable Gencomm pages SMS messaging start & stop functionality DC Supply: CONTINUOUS VOLTAGE RATING - 8V to 35V Continuous CRANKING DROPOUTS - Able to survive 0V for 50 mS, providing supply was at least 10V before dropout and supply recovers to 5V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking. MAXIMUM OPERATING CURRENT - 340 mA at 12V, 160 mA at 24V MAXIMUM STANDBY CURRENT - 160 mA at 12V, 80 mA at 24V CHARGE FAIL/EXCITATION RANGE - 0 V to 35V Generator: VOLTAGE RANGE - 15V to 415V AC (Ph to N) VOLTAGE RANGE – 26V to 719V AC (Ph to N) FREQUENCY RANGE - 3.5 Hz to 75 Hz Outputs: OUTPUT A (FUEL) - 15A DC at supply voltage OUTPUT B (START) - 15A DC at supply voltage OUTPUTS C & D – 8A 250V (Volt Free) AUXILIARY OUTPUTS E, F, G, H – 2A DC at supply voltage Magnetic Pick Up: VOLTAGE RANGE - +/- 0.5V to 70V FREQUENCY RANGE - 10,000 Hz (max) Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
