Dse Deep Sea Electronics Dse9470 24 Volt 10 Amp Dc Battery Charger 24v 10a 9470

US $1100

Forest Grove, Oregon, United States
Jun 20th

Open on mobile:
QR code

Deep Sea Electronics DSE9470 24volt 10amp DC Battery Charger The DSE9470 is an intelligent battery charger that can be programmed for different charging curves to maximise the life of the battery. The DSE9470 is programmed using the user-friendly DSE Configuration Suite PC software. The charger can be either mounted via DIN rail or to the chassis, using the fixing holes that are built into the case. The charger’s stylish design includes three coloured LEDs to indicate charging status and fault conditions. The charger does not include any moving parts to give added durability and reliability. It will also continue to operate during cranking and running. MAIN FEATURES ADVANCED FEATURES Multi-Stage Intelligent Charging • Automatic three stage charging • Constant current – Maximum current available during charge recovery phase • Constant voltage • Chargers automatically return to float mode when charging is complete • Digital microprocessor technology • Three LEDs indication • Low Output Ripple • Makes the chargers ideal for all battery types Automatic Boost Mode • Boosts and equalises cell charge improving battery performance and life Full Protection • AC input Under voltage • AC input Over voltage • Battery charger output Over voltage • Battery charger output Over current • Short circuit protection • Battery temperature compensation with over temperature protection • Output short circuit and Inversion polarity • Automatic power de-rating at high ambient temperatures Power Save Mode • Once the battery is fully charged the chargers switch to Eco-Power to save energy. Communication • * Can be intgrated in to external systems through MODBUS RTU using RS485 • Fully configurable via DSE Configuration Suite PC Software * Feature to follow shortly KEY BENEFITS • Fully flexible to maximise the life of the battery • Suitable for a wide range of battery types • No moving parts for longer battery charger life • Switched mode design • Charge fail output • Minimum 86% efficiency throughout full operating range • No external intervention for boost mode • Multiple chargers can be linked together to provide larger current output SPECIFICATION AC SUPPLY VOLTAGE RANGE 90 V to 305 V (L-N) FREQUENCY RANGE 48 Hz to 64 Hz (L-N) DC OUTPUT 24 V DC at 10 A RIPPLE AND NOISE <1% EFFICIENCY >86% REGULATION LINE <0.001% LOAD 1% TEMPERATURE SENSOR INPUT PT1000 PROTECTIONS Short Circuit DC Over Voltage DC Over Current Reverse Polarity Over Temperature AC Under & Over Voltage DIMENSIONS OVERALL 70 mm x 200 mm x 130 mm 2.7” x 7.9” x 5.1” WEIGHT 0.75 kg STORAGE TEMPERATURE RANGE -40 oC to +85 oC Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
