Dso138 2.4 Tft Soldered Fully Welded Digital Oscilloscope Kit W/ Case Diy 12bit

US $36.13

suzhou, China
Jul 4th

Open on mobile:
QR code

Product Description DSO138 2.4 TFT Soldered Fully Welded Digital Oscilloscope Kit W/ Case DIY 12bit Features: 100% brand new and high quality Made of high-quality materials, durable The kit uses the ARM Cortex-M3 processor (STM32F103C8), including a 2.4-inch color TFT display, which can be used as an ARM test development board. Secondary development can be carried out on the basis of this kit, for example, it can be changed to millivoltmeter, data logger, etc. The vertical displacement is adjustable with instructions. With automatic, regular and one-off modes, it is easy to capture instantaneous waveforms. It can be triggered by rising or falling edge. Observable previous trigger waveform (negative delay). The waveform display can be frozen at any time (HOLD function). Comes with 1Hz/3.3V square wave test signal source. With digital display of waveform parameters, including frequency, period, pulse width, duty cycle, MAX./MIN./AVG./Peak-Peak/virtual value. Waveform storage function: the waveform will not be lost after power off. Short circuit and open circuit detection: can help users find welding errors. TFT controller identification function. Product parameters: Model: DSO138 Type: Welded Maximum real-time sampling rate: 1Msps Precision: 12 bits Sampling buffer depth: 1024 bytes Analog bandwidth: 0-200KHz Vertical sensitivity: 10 mV/Div-5V/Div (1-2-5 progressive method) Input impedance: 1M Maximum input voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe) Coupling mode: DC/AC/GND Horizontal time base range: 10mus/Div-50s/Div (1-2-5 progressive method) Power supply voltage: DC 9V PCB size: 117 * 76mm / 4.6 * 3in Screen size: 52 * 40mm / 2 * 1.57in Packing size: 18*12.5*3cm/7.08*4.92*1.18in Package list: 1 *DSO138 2.4" TFT Welded Fully Welded Pocket Digital Oscilloscope 1 *Acrylic DIY shell (need to assemble) 1 *Probe 1 *User Manual (English) Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Type	Welded
Brand	Unbranded
Maximum Real-Time Sampling Rate	1Msps
Oscilloscope Type	Digital Oscilloscope
Precision	12 bits
Package Contents	Oscilloscopekit
Sampling buffer depth	1024 bytes
Model	DSO138
Coupling mode	DC/AC/GND
UPC	Does not apply
