Dso203 Nano 4 Channel Mini V2 Quad Pocket Digital Oscilloscope

US $2500

Canton, China
Jun 9th

Open on mobile:
QR code

Trade_Spotting Trade_Spotting is a well-known online brand specialized on development board, professional test equipments. As a professional and reliable eBay seller, we source from SainSmart's manufactory directly before testing and packing. ARM DSO203 4 Channel Mini Nano V2 Quad Pocket Digital Oscilloscope Click here to Buy It without Waiting!! Overview Fulfilling the basic engineering requirements, DSO 203 is a pocket-sized 4 channel digital storage oscilloscope for common electronic engineering tasks. DSO 203 is based on ARM cortex M3 (STM32VCT6), providing 72MSa/s Sampling Rate with integrated FPGA and high speed ADC, equipped with400*240 TFT LCD widescreen ,USB connection and rechargeable battery. Convenient to carry as it weights only 80g without battery. Features 1. 3" 240 x 400 widescreen color TFT LCD screen, STM32 is the master MCU, with the FPGA to implement the control and management of external ADC and data cache. 2. MCU and the FPGA are selected QFP100 package, ADC selected QFP48 package. 3. Two 72MSa/s analog channels and two digital channels. 36MSa/s+36MSa/s sampling frequency, the use of the ADC AD9288-40 chip, single-channel maximum sampling frequency of the 72MSa/s. 4. FIFO RAM has a maximum operating frequency of use of> 200MHz low-power FPGA to achieve. 5. The AD9288-40 Overclocking to achieve 72MSa/s+72MSa/s sampling frequency, so that the maximum sampling rate up to 144MSa/s. 6. As low power, low-cost, QFP package and other conditions of the FPGA, storage capacity is not large, so DSO203 sampling depth of the current situation for the multi-channel 4096 points per channel, single-channel work cases, 8192 points. 7. Bandwidth: 8MHz Specification Analog channel * 2 [CH_A] [CH_B] Digital channel * 2 [CH_C] [CH_D] Vertical Scale 50mV-10V/div (x1 probe) Vertical solution 8 bit Input coupling AC/DC Max input voltage 80Vpp (x2 probe) Storage 4K per channel Software trigger type edge, pulse, level (to be added) Hardware trigger type edge Trigger source CH1/CH2/EXT Test Signal generator 10Hz to 1Mhz Storage internal 2MB USB disk Auto measure Vmax, Vmin, Vpp, Vavr, Vrms, Freq, Period, Pulse, Duty Cursor measurement Level, Voltage Display mode CH1, CH2, EXT, CH1+CH2, CH1-CH2, CH1*CH2 Sampling mode real time Sampling rate 1kSa/s - 72MSa/S Power Li-ion battery Dimension 98 * 60 * 14.5 mm Weight 80g (without battery) Package List 1x DSO203/Quad with battery 2x Probes 1x High quality Mini USB Cable 1X Flannel Bag Relative Items DSO150 250Ksps Rate AVR 8Bit Core Ship to Wordwide DSO201 Handheld,4096 Point memory depth,1MHz bandwidth Ship to Wordwide DSO203,4 CH,72 MHz Analog Bandwidth,72MSa/S Ship to Wordwide DSO203 Aluminium,4 CH,72 MHz Analog Bandwidth,72MSa/S Ship to Wordwide US Shipping US Shipping US Shipping US Shipping Shipping Payment Return Feedback Communication 1.Item will be shipped within 1-2 working days after full payment is cleared. Tracking number will be sent to all customers upon package shipment. 2.Delivery time is different in accordance to shipping address and shipping methods. -Economy shipping from China: about 20-30 biz days. -ePacket delivery (EUB) from China to US: about 10-15 biz days. -Expedited shipping from China takes about 3-5 biz days via DHL/UPS and 9-15 biz days via EMS. -Standard shipping (Royal Mail Tracked) from UK warehouse to local customers: about 3-5 biz days. -Standard shipping from US warehouse: about 3-7 biz days. -Expedited shipping from US warehouse: about 3-5 biz days. 3.Delivery time depends on destination,logistics mode and other factors. If you have not received your shipment within 30 days from payment, please feel free to contact us. We will track the shipment and get back to you as soon as possible with a reply. Customer`s satisfaction is our goal. 1. We accept payment via PAYPAL ONLY which provides full-scale buyer protection policy up to $500. We only ship to confirmed PAYPAL addresses.Please makesure payment address in PayPal is correct. 2. All major credit cards are accepted through our secure payment processor PayPal. 3. Payment must be received within 7 business days of auction closing. 1.60 days money back return policy. If you are not satisfied when you?receive your item, please return it within 60 days for a replacement or money back. Please contact us for return address before you send it back. 2. If item defective, in 3 months we will send you a replacement without extra charge, or offer refund upon faulty received. after 3 months you are still welcomed to send it back to us for exchange. Buyer may responsible for all return shipping costs. 3.In case you receive wrong products due to shipping error, please contact us for exchange or refund. If it's damaged , please refuse to accept and contact us as soon as possible. Please email us before leaving any negative feedback or open any dispute on PayPal. We care about our valued customers, and will always try to help you. So if you have any problems, please e-mail us immediately. We try our best to reply to your emails as soon as possible. If you do not receive any reply from us, please check your email ensuring your mailbox has not reached full size. You can contact us by Ebay messages.
