Dspic30f2020-30i/sp Dsp Pic Microcontroller

US $300

Lewis, New York, United States
Jun 29th

Open on mobile:
QR code

Original Electronic Components dsPIC30F2020-30I/SP Lot size: 1 Case: DIP-28 PIC microcontroller supporting multi-loop digital power control applications Genuine components from USA; No China parts! !!! See Buy-It-Now listing for this item !!! !! See my other items !! Architecture 16-bit CPU Speed (MIPS) 30 Memory Type Flash Program Memory (KB) 12 RAM Bytes 512 Temperature Range C -40 to 125 Operating Voltage Range (V) 3 to 5.5 I/O Pins 21 Pin Count 28 System Management Features LVD nanoWatt Features Fast Wake/Fast Control Digital Communication Peripherals 1-UART, 1-SPI, 1-I2C Analog Peripherals 1-A/D 8x10-bit @ 2000(ksps) Comparators 4 CAN (#, type) 0 None Capture/Compare/PWM Peripherals 2 Motor Control PWM Channels 8 Timers 3 x 16-bit 1 x 32-bit Parallel Port GPIO Hardware RTCC No DMA 0 Features High-Performance Modified RISC CPU: # Modified Harvard architecture # C compiler optimized instruction set architecture # 83 base instructions with flexible addressing modes # 24-bit wide instructions, 16-bit wide data path # 12 Kbytes on-chip Flash program space # 512 bytes on-chip data RAM # 16 x 16-bit working register array # Up to 30 MIPs operation: # 32 interrupt sources # Three external interrupt sources # 8 user-selectable priority levels for each interrupt # 4 processor exceptions and software trap DSP Engine Features: # Modulo and Bit-Reversed modes # Two 40-bit wide accumulators with optional saturation logic # 17-bit x 17-bit single-cycle hardware fractional/ integer multiplier # Single-cycle Multiply-Accumulate (MAC) operation # 40-stage Barrel Shifter # Dual data fetch Peripheral Features: # High-current sink/source I/O pins: 25 mA/25 mA # Three 16-bit timers/counters; optionally pair up 16-bit timers into 32-bit timer modules # Four 16-bit Capture input functions # Two 16-bit Compare/PWM output functions - Dual Compare mode available # 3-wire SPI modules (supports 4 Frame modes) # I2CTM module supports Multi-Master/Slave mode and 7-bit/10-bit addressing # UART Module Power Supply PWM Module Features: # Four PWM generators with 8 outputs # Each PWM generator has independent time base and duty cycle # Duty cycle resolution of 1.1 ns at 30 MIPS # Individual dead time for each PWM generator: - Dead-time resolution 4.2 ns at 30 MIPS - Dead time for rising and falling edges # Phase-shift resolution of 4.2 ns @ 30 MIPS # Frequency resolution of 8.4 ns @ 30 MIPS # PWM modes supported: - Complementary - Push-Pull - Multi-Phase - Variable Phase - Current Reset - Current-Limit # Independent Current-Limit and Fault Inputs # Output Override Control # Special Event Trigger # PWM generated ADC Trigger Analog Features: ADC # 10-bit resolution # 2000 Ksps conversion rate # Up to 12 input channels # Conversion pairing allows simultaneous conversion of two inputs (i.e., current and voltage) with a single trigger # PWM control loop: - Up to six conversion pairs available - Each conversion pair has up to four PWM and seven other selectable trigger sources # Interrupt hardware supports up to 1M interrupts per second COMPARATOR # Four Analog Comparators: - 20 ns response time - 10-bit DAC reference enerator - Programmable output polarity - Selectable input source - ADC sample and convert capable # PWM module interface - PWM Duty Cycle Control - PWM Period Control - PWM Fault Detect # Special Event Trigger # PWM-generated ADC Trigger Special Microcontroller Features: # Enhanced Flash program memory: - 10,000 erase/write cycle (min.) for industrial temperature range, 100k (typical) # Self-reprogrammable under software control # Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST) # Flexible Watchdog Timer (WDT) with on-chip low power RC oscillator for reliable operation # Fail-Safe clock monitor operation # Detects clock failure and switches to on-chip low power RC oscillator # Programmable code protection # In-Circuit Serial Programming (ICSP) # Selectable Power Management modes - Sleep, Idle and Alternate Clock modes CMOS Technology: # Low-power, high-speed Flash technology # 3.3V and 5.0V operation (10%) # Industrial and Extended temperature ranges # Low power consumption Purchases can only be changed or cancelled before payment. Delivery dates provided by eBay are not guaranteed. Transit time can be 5-7 business days in USA after 1-2 day processing, however USPS does not guarantee these times, and can exceed them. If you have any time constraints, please contact seller before bidding / buying, to discuss shipping arrangements and delivery dates. PAYMENT CLOSES ORDER AND COMMITS IT FOR SHIPPING. Your shipping label is created and billed along with insurance the moment you click "PAY". Paypal and insurance charges are non-recoverable. No cancellation possible after payment. Any returns not resulting from seller wrongdoing will be assessed a restocking fee of 18% and will forfeit shipping costs. International transit times can reach 8 weeks, 10 weeks for Italy and Brazil. Contact seller for alternate shipping options if this is not acceptable to you. RETURNS can only be made with parts that have not been soldered. Before using, buyer must test one part as per the test information in the manufacturer's data sheet. This test is easy for any engineer or technician. This product is aimed at the industrial market. It is not a consumer product.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Microchip
Model	dsPIC30F2020-30I/SP1TG
MPN	dsPIC30F2020-30I/SP1TG
Country/Region of Manufacture	United States
UPC	Does Not Apply
EAN	Does Not Apply
