Dt-9926 Professional Digital Multimeters Dmm

US $770

hk, Hong Kong
May 29th

Open on mobile:
QR code

Multimeters DT-9926 Professional Digital Multimeters DMM MIB-INSTRUMENTS "Can Buy It Now in my ebay store" DT-9926 Professional Digital Multimeter's basic info DT-9926 set the standard with a combination of precise, features, easy-to-use, safety and reliability. It features a waterproof, rugged design for heavy duty use. This meter is conformance to double insulation per EN61010-1 and IEC61010-1 2nd Edition (2001) to Category IV 600V and Category III 1000V; Pollution Degree 2. The meter also meets UL 61010-1, 2nd Edition (2004), CAN/CSA C22.2 No. 61010-1 2nd Edition (2004), and UL 61010B-2-031, 1st Edition (2003) Description of DT-9926 Professional Digital Multimeter Features: 1. 6000 digital display counts with backlit 2. Analog bargraph/segment 3. Relative mode allows you to make measurements relative to a stored reference value 4. Data hold, MAX/MIN recording mode 5. Auto ranging / Manual range selection 6. Auto power off and low battery indication 7. Measurement Rate: 2 times per second, nominal 8. Wide capacitance range. DC Voltage measurement: Range: 600mV, 6V, 60V, 600V, 1000V Basic accuracy: +0.09% Resolution: 0.1mV AC Voltage measurement: Range: 6V, 60V, 600V, 1000V Basic accuracy: +0.8% Resolution: 0.001V DC Current measurement: Range: 600A, 6000A, 60mA, 600mA, 6A, 10A Basic accuracy: +1.0% Resolution: 0.1A AC Current measurement: Range: 600A, 6000A, 60mA, 600mA, 6A, 10A Basic accuracy: +1.5% Resolution: 0.1A Resistance measurement: Range: 600W, 6kW, 60kW, 600kW, 6MW, 60MW Basic accuracy: +0.3% Resolution: 0.1W Frequency(electronic) measurement: Range: 9.999Hz, 99.99Hz, 999.9Hz, 9.999kHz, 99.99kHz, 999.9kHz, 9.999MHz Basic accuracy: +0.1% Resolution: 0.001Hz Frequency(electrical) measurement: Range: 10.00-400Hz Basic accuracy: +0.5% Resolution: 0.01Hz Duty Cycle Measurement Range: 0.1 to 99% Basic accuracy: +1.2% Resolution:0.1% Diode Check and Continuity Test: Diode Test: Test current of 0.9mA maximum, open circuit voltage 2.8V DC typical Continuity Check: Audible signal will sound if the resistance is less than 100W (approx.), test current <0.35mA Specifications: Function Range Basic Accuracy Resolution DC Voltage 600mV 0.1mV +(0.09% reading + 2 digits) 6V 0.001V 60V 0.01V 600V 0.1V 1000V 1V +(0.15% reading + 2 digits) AC Voltage 50 to 60Hz 40Hz to 1KHz 6V 0.001V +(1.0% reading + 3 dgts) +(2.0% reading + 3 dgts) 60V 0.01V 600V 0.1V 1000V 1V +(1.2% reading + 3 dgts) +(2.5% reading + 3 dgts) All AC voltage ranges are specified from 5% of range to 100% of range DC Current 600uA 0.1uA +(1.0% reading + 3 digits) 6000uA 1uA 60mA 0.01mA 600mA 0.1mA 6A 0.001A +(1.5% reading + 3 digits) 10A 0.01A (20A: 30 sec max with reduced accuracy) AC Current 40Hz to 1kHz 600uA 0.1uA +(1.5% reading + 3 digits) 6000uA 1uA 60mA 0.01mA 600mA 0.1mA 6A 0.001A +(2.0% reading + 3 digits) 10A 0.01A (20A: 30 sec max with reduced accuracy) All AC voltage ranges are specified from 5% of range to 100% of range Payment Shipping We accept Paypal, credit card through Paypal. Buyer may need to pay for import tax depend on your country's custom. You can ask us for more detail. We ship to international and item will be shipped by airmail from HongKong. Items are shipped within 2-3 business day after receive cleared payment. An additional USD2 for insurance Most item will arrive within 8-14 business days. It depend on your location. In some case, ship to some countries will take over 3 weeks, especially brazil, Italy and France . Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Aug-12-14 at 02:37:10 PDT, seller added the following information: Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
