Dua01cb23500v - Carlo Gavazzi Voltage Monitors

US $190

Monroe, North Carolina, United States
Jan 29th

Open on mobile:
QR code

Brand new monitor made by Carlo Gavazzi. 3 phase monitoring makes it easy to troubleshoot which phase is the culprit. On Jul-23-13 at 15:56:09 PDT, seller added the following information:Monitoring Relays 1-Phase AC/DC Over Voltage - AC Over Current Types DUA01, PUA01 DUA01 Product Description Ordering Key Housing Function Type Item number Output Power supply Range Supply: 24 to 48 VAC/DC DUA 01 C D48 500V PUA 01 C D48 500V Output Specifications Output Rated insulation voltage Contact ratings (AgSnO2) Resistive loads AC 1 DC 12 Small inductive loads AC 15 DC 13 Mechanical life Electrical life Operating frequency Dielectric strength Dielectric voltage Rated impulse withstand volt. • AC/DC over voltage monitoring relay • Selection of measuring range by DIP-switches • Measuring ranges: 2 to 20 VAC/DC, 5 to 50 VAC/DC, 20 to 200 VAC/DC, 50 to 500 VAC/DC, 0.4 to 4 Vp AC • Adjustable voltage limit on relative scale • Adjustable hysteresis • Programmable latching at set level • Output: 8 A SPDT relay normally de-energized • For mounting on DIN-rail in accordance with DIN/EN 50 022 (DUA01) or plug-in module (PUA01) • 22.5 mm Euronorm housing (DUA01) or 36 mm plug-in module (PUA01) • LED indication for relay and power supply ON • Galvanically separated power supply DUA 01 C B23 500V DUA01 and PUA01 are pre- cise AC/DC over voltage monitoring relays. They can also be used as 1-phase or 3-phase over current moni- toring relays when connect- ed with MI or MP current Type Selection Mounting DIN-rail Plug-in Input Specifications Input (voltage level) DUA01 PUA01 Measuring ranges Direct Selectable by DIP-switches 2 to 20 VAC/DC 5 to 50 VAC/DC 20 to 200 VAC/DC 50 to 500 VAC/DC 0.4 to 4 Vp AC Max. voltage for 1 s MI and MP CT ranges transformers. Owing to the built-in latch function, the ON-position of the relay output can be maintained. The red LED indicates the alarm status. Output SPDT SPDT Supply: 115/230 VAC DUA 01 C B23 500V PUA 01 C B23 500V Terminals Y1, Y2 Terminals 5, 7 Int. resist. > 500 k? > 500 k? > 500 k? > 500 k? > 500 k? AAC rms 0.5 to 5 A 2 to 20 A 10 to 100 A 50 to 500 A Max. volt. 600 V 600 V 600 V 600 V 600 V 1000 V Max. curr. 20 AAC 50 AAC 250 AAC 750 AAC Terminals Z1, Y1 Terminals 8, 9 > 10 k? < 500 ? > 500 ms SPDT relay 250 VAC ? 8 A @ 250 VAC 5 A @ 24 VDC 2.5 A @ 250 VAC 2.5 A @ 24 VDC >= 30 x 106 operations >= 105 operations (at 8 A, 250 V, cos ? = 1) = 2 kVAC (rms) 4 kV (1.2/50 ?s) 1-ph.: MI 5 MI 20 MI 100 MI 500 Note: 3-ph.: MP 3005 MP 3020 MP 3100 MP 3500 The input voltage cannot raise over 300 VAC/DC with respect to ground (PUA01 only) Contact input DUA01 PUA01 Disabled Enabled Latch disable PUA01On Jul-23-13 at 16:00:10 PDT, seller added the following information:Supply Specifications Power supply Rated operational voltage through terminals: General Specifications (cont.) Accuracy Temperature drift Repeatability Indication for Power supply ON Output relay ON Environment Degree of protection Pollution degree Operating temperature Storage temperature Overvoltage cat. III (IEC 60664, IEC 60038) 24 to 48 VAC/DC ± 15% 45 to 65 Hz, insulated 115/230 VAC ± 15% 45 to 65 Hz, insulated DC supply 2 kV 4 kV 4 kV AC supply 4 kV 4 kV 4 kV 4 VA 2W (15 min warm-up time) ± 1000 ppm/°C ± 0.5% on full-scale LED, green LED, red (EN 60529) IP 20 3 (DUA01), 2 (PUA01) -20 to 60°C, R.H. < 95% -30 to 80°C, R.H. < 95% 22.5 x 80 x 99.5 mm 36 x 80 x 94 mm PA66 or Noryl Approx. 150 g Max. 0.5 Nm acc. to IEC 60947 EN 60255-6 UL, CSA L.V. Directive 2006/95/EC EMC Directive 2004/108/EC According to EN 60255-26 According to EN 61000-6-2 According to EN 60255-26 According to EN 61000-6-3 A1, A2 or A3, A2 2, 10 or 11, 10 Dielectric voltage Supply to input Supply to output Input to output (DUA01) (PUA01) D48: B23: Rated operational power AC DC General Specifications Housing Dimensions Material Weight Screw terminals Tightening torque Product standard Approvals CE Marking EMC Immunity Emissions DUA01 PUA01 Reaction time Alarm ON delay Alarm OFF delay Mode of Operation DUA01 and PUA01 monitor both AC and DC over volt- age. When connected with MI or MP current trans- former (using the 0.4 - 4 Vp range) they can monitor 1- phase or 3-phase AC cur- rents up to 500 A. Example 1 (connection between termi- nals Z1, Y1 or 8, 9 - latch function enabled) The relay operates and latches in operating position when the measured value exceeds the set level. Pro- vided that the voltage has dropped min. 4% below the set point (see hysteresis), the relay releases when the interconnection between ter- minals Z1, Y1 or 8, 9 is inter- rupted or the power supply is interrupted as well. Range - Level Setting Example 2 (MI CT) (no connection between ter- minals Z1, Y1 or 8, 9) The relay operates when the current flowing through the CT exceeds the set level. It releases when the current drops min. 4% below the set level (see hysteresis) or when power supply is inter- rupted. Example 3 (MP CT) (no connection between ter- minals Z1, Y1 or 8, 9 - latch function disabled) The relay operates when the maximum current flowing through the CT exceeds the set level. It releases when the maximum current drops min. 4% below the set level (see hysteresis) or when power supply is interrupted. Adjust the measuring range setting the DIP switches 1 to 4 as shown below. To access the DIP switches open the grey plastic cover using a screwdriver as shown below. Centre knob: Setting of voltage on relative scale: from 10 to 110% of the full-scale value. Hysteresis: Approx. 4% of set value, it can be extended by insert- ing a resistor between termi- nals Z1, Y1 or 8, 9. Approx. resistor values: 10%: 25%: 50%: 75%: Latch: 180 k? 47 k? 22 k? 15 k? < 500 ? < 100 ms (voltage rising from -20% to +20% set value) < 300 ms (voltage decreasing from +20% to -20% set value) Measuring range OFFONOFFOFF 0.4to4Vp ON OFF OFF OFF 2 to 20 VAC/DC OFF OFF OFF OFF 5 to 50 VAC/DC ON OFF ON OFF 20 to 200 VAC/DC ON OFF OFF ON 50 to 500 VAC/DC

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Carlo Gavazzi
Model	DUA01CB23500V
