Dual Dc Stepper Motor Drive Controller Board Module Tb6612fng Replace L298n Ap

US $2.69

Hong Kong, Hong Kong
Jun 9th

Open on mobile:
QR code

? ?? Description: Features: The TB6612FNG motor driver can control up to two DC motors at a constant current of 1.2A (3.2A peak). Two input signals (IN1 and IN2) can be used to control the motor in one of four function modes - CW, CCW, short-brake, and stop. The two motor outputs (A and B) can be separately controlled, the speed of each motor is controlled via a PWM input signal with a frequency up to 100kHz. The STBY pin should be pulled high to take the motor out of standby mode.CJMCU. Logic supply voltage (VCC) can be in the range of 2.7-5.5VDC, while the motor supply (VM) is limited to a maximum voltage of 15VDC. The output current is rated up to 1.2A per channel (or up to 3.2A for a short, single pulse). Board comes with all components installed as shown. Decoupling capacitors are included on both supply lines. All pins of the TB6612FNG are broken out to two 0.1" pitch headers; the pins are arranged such that input pins are on one side and output pins are on the other. Standby control to save power CW/CCW/short brake/stop motor control modes Built-in thermal shutdown circuit and low voltage detecting circuit All pins of the TB6612FNG broken out to 0.1" spaced pins Filtering capacitors on both supply lines Specifications: Power supply voltage: VM=15V max, VCC=2.7-5.5V Output current: Iout=1.2A(average) / 3.2A (peak) Net Weight: 5 g Dimensions: 20mm x 20mm Color: red Package Included: 1* The TB6612FNG motor driver module ?? We accept PayPal only. Payment must be received within 3 Days from the date of purchase. Please leave note in PayPal when making the payment if you have any special request (colors/size). Orders will be processed instantly and dispatched in same day normally, so we do NOT accept any Email/Message note before or after you place orders. All the items will be dispatched within 1 business day by Airmail after the payment is clear. Items will arrive in 7-25 business days. The arrival time depends on some factors and different areas:Please choose some local sellers, if you cannot wait patiently in the shipping time we Country Delivery Time Working Days (not including holiday) 5-7 8-11 12-14 15-19 20-22 >22 Working Days + Saturday + Sunday 5-9 10-15 16-20 21-25 26-30 >31 United States Rate (item arrived) 5 .1% 50.1% 29.6% 10.5% 4.7% Refund United Kingdom Rate (item arrived) 9.9% 63.2% 19.1% 3.4% 4.4% Refund Australia Rate (item arrived) 21.4% 50.0% 14.3% 7.2% 7.1% Refund France Rate (item arrived) 10.5% 28.6% 43.8% 10.1% 7.0% Refund Germany Rate (item arrived) 11.1% 22.2% 30.3% 20.9% 15.5% Refund Canada Rate (item arrived) 0.0% 47.1% 31.4% 17.6% 3.9% Refund Spain Rate (item arrived) 3.5% 25.0% 47.9% 12.9% 10.7% Refund We offer 14 days return policy. Please contact us within 14 days t from the date you receive your order if you have any issues with the product and would like to return. All returned items MUST BE in the original packaging and you MUST PROVIDE us with the shipping tracking number, specific reason for the return, and your eBay ID. We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included, AFTER BOTH Buyer and Seller cancel the transaction from eBay. OR, you may choose to have a replacement. Buyer is responsible for return shipping cost. If you have any questions, please feel free to email our service specialists 24 Hours a Day, 7 Days a Week.We will reply you ASAP. If no response within 24 Hours, please check the spam in your mail box. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help. Our aim is to provide Top Level Customer Service, normally so we will try our best to solve any problem. Please DON'T leave negative or neutral feedback if you haven't received item in 30 days, because we have mentioned the shipping time repeatedly. On Sep-23-15 at 22:25:08 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
MPN	Does not apply
UPC	Does not apply
