Dual Display0.28“ 4in1 Red Digital Volt Amp Panel Meter Thermometer Power Meter

US $13.19

Guangzhou ,Guangdong, China
Jun 9th

Open on mobile:
QR code

welcome to our shop! Description 4in1 4 digits red led Digital voltmeter Ammeter Thermometer power meter 33V/3A #1400154 Note: this meter does not contain 18B20 sensor ,you have buy it by yourself ! 18B20 temperature sensor has 2 kinds.one kind with line And another kind without lines! Products features: This meter has the perfect function and put four function of measuring the voltage, current, temperature and power into this one meter. when the current is measured, the power is firom the measurement circuit and it don't need the isolated power. so the current is easy to be measured. It has high precison in voltage measurement and voltage compensation in measurment circuit. it can automatically compensate voltage drop according to current size on the wire. Technical Parameters: Weight: 23g Display color: Red Display mode: Dual 0.28" LED digital 4 bit tube update rate: About 200 ms/time Physical size: 48 x 29 x 26 mm (L*W* H) Opening size: 45 x 26 mm (L*W) Supply voltage: DC 3.5-28V Lead wire length: 14 cm(Five wires) Measurement range: DC 0-999.9mA-3.000A(current) DC 0.00-33.00V(voltage) (Resolution 0.01V) -55 °c ~ 110 °c(Temperature) (Resolution 0.1 ℃) DC 0.9-99.9W (Power)(Resolution 0.1W) Measurement accuracy: ± (0.3% + 2words) Display discription: Voltage current meter mode:Boot default display voltage current meter mode The above digital tube display voltage; there are four fixed display precision. the measurement range is 0.00-33.00V; the mimimum resolusion is 10mV The below digital tube display current; there are four fixed display precision; the measurement range is 0-999.9mA-3.000A. When the measuring current is below 1A, it display***.*mA,the resolusion is 0.1mA; When the measuring current is higher than 1A, it display*.***A,the resolusion is 1mA; Temperature power meter mode:Press the button one time, the meter is switched totemperature power meter mode. The above digital tube display temperature; there are three fixed display precision. The fourth bit is sign bit, displaying 'C'. The measurement range is -55 °c ~ 110 °c; the mimimum resolusion is 0.1°c. The below digital tube display power; there are three fixed display precision. The fourth bit is sign bit, displaying 'P'. The measurement range is 0.0- 99.9W; the mimimum resolusion is 0.1W . When the 18B20 chip is not inserted into the meter, the above digital tube display"-N-C". When the temperature exceeds the measurement range, the above digital tube display "---C". When the power exceeds the measurement range, the below digital tube display "---P". The voltage compensation function discription: When the system load is bigger, there will be some certain voltage drop on the connecting wire. So the header will not display the right output voltage of the system supply power. Now the voltage compensation function can solve this problem by moderate compesation of the voltage loss on connecting wire. So the meter can measure the precise voltage of the system supply power. When you use this function, you must prepare a more than four and half digit multimeter. Please connect it with the output piont of the system supply power, and then shut down the power of the voltage current. Then keeping press the button on the back of the voltage current meter and give the meter power at the same time. Now the below digital tube will display [**]; ** indicate the storage compensation voltage level(when the meter was just produced, the level is 00, display [00], meaning no compensation). when you loose the button, the below tube display --** When it displays --**, it indicates the meter is going in the state of setting compensation voltage. Please connect the the bigger load in the circuit( we advise the current of the load should be higher than 2A, so the compensation will be more precise.) ,then see the voltage which the above tube show. Pess shortly the button one time, it will be automatically added one level (The maximum commpesation level is 99), until the voltage on the meter is the same to the voltage on the multimeter. Keeping press the button more than 2s to store the current compension voltage. so you will measure the volage by this compensation level. If you want to shunt down the compensation, please adjust level to 00. Instruction of wiring Red thin wire (VCC):Power input+ 3.5-28V(NOTE: If the measuring signal is lower than 28V and have abundant power supply, it can be used as power supply for the module [black wire and yellow wire are contacted together to use]) Black thin wire(GND):Power input- Measurement signal - 3.5-28V Yellow thin wire (VIN):Measurement signal+ (0-33.00V) Red thick wire (I+):Current input+ (connect with load negative) Black thin wire(I-):Currentinput-(in series in power supply negative) Note:the connection instruction of temperature sensor, please refer to the back of product picture Wiring instruction: Voltage current meter with isolated power supply Voltage current meterin the measurement system for power supply System supply power-1 System supply power-2 The temperature sensor wiring instruction Note: this meter does not contain 18B20 sensor ,you have buy it by yourself ! 18B20 temperature sensor has 2 kinds.one kind with line And another kind without lines! packing including: 1x 4in1 4 digits red meter Payment We only accept payments via paypal. All payments must be prepaid, no Cash and COD payment. We will ship the item to the address on your paypal payment notice, Please confirm your shipping address in the PayPal Account. If you have any problem about payment , please contact us. Delivery details Item will be shipped within 3 working days after full payment is received. We ship worldwide with flat rate shipping by post Air mail, the shipment usually takes 15-45 business days . We can also provide express post by EMS(5-8 days) or UPS(4-5 days). The cost is higher than standard postage, extra shipping fees is needed. if you need express post please contact us ! About us We will leave positive feedback to buyer as soon as buyer pays for the item .Your satisfaction is our first priority. Please leave us positive feedback upon satisfaction of the item. Please email us before leaving negative and neutral feedback. We will try our best to solve the issue. We will leave positive feedback to buyer as soon as buyer pays for the item . Contact us we do try respond as quickly as possible. Due to time zone difference, please allow 12~24 hours to get your mail replied. If you have any questions, Please contact with us via ebay message or our customer service e-mail .thanks for your buying ,wishes you have a happy shopping from our shop ! On Sep-17-15 at 13:13:48 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	product name	Digital voltmeter Ammeter
Lead wire length	14 cm(Five wires)
module name	Thermometer power meter
Measurement accuracy	± (0.3% + 2words)
Physical size	48 x 29 x 26 mm (LW H)
Brand	digital voltmeter ammeter
Opening size	45 x 26 mm (L*W)
MPN	Does Not Apply
Supply voltage	DC 3.5-28V
UPC	Does not apply
