Dual Mode/power Output Pwm Dimming Speed Control Module Adjustable Period Delay

US $3.41

Shenzhen ,Guangdong, China
Jul 19th

Open on mobile:
QR code

Store CategoriesStore Categories Electronic Components&toolMagnet Welding toolThermal Paste Solder Paste Soldering Wire Spot Welders Socket Connector Electronic toolsEngraver Pen Repair Watch tool Rain Gauge LED LightLED Lamp Base LED String LED Light Bulb LED DIP Light LED SMD Light Diodes/Rectifiers Capacitor/Resistor Switch other ICsother Arduino ModuleArduinoNodemcu ESP series WEMOS D1 Mega Motor Drive Module other Module & Development BoardAmplifier Signal Generator/Transmitter USB Module Development Board Power Module?DC-DC and DC-AC? Clock Module Bluetooth Module Breadboard Digital Thermostat Controller LCD/LED/TFT Disply Logic board WIFI/Wireless Module Server Module Relay Sensor Voice Module Voltage Regulator other MeterCurrent Voltage meter Tester Multimeter AnalysisInstruments other Raspberry/Orange PiOrange Pi Expansion Board Raspberry Pi other 3D Printers & AccessoriesBearing Jaw Shaft Pump other Flight Control APMDrone accessories RC Drone other Auto Parts & AccessoriesGrille Logo Car Sun visor Car Lights Car DVRs GPS & Accessories Car Electronics Parts/Accessor Car Audio & Monitor Car Alarm & Security Diagnostic Scan Tool Car Repair & Maintenance Electric Scooters Car Cradles & Mounts Motor other Fashion/BeautyBeautyBeauty tools Makeup brush Earring/Quartz watches Jewelry Baby Products other Fashion/HealthMaternal and Child Health Healthy Medical ProductFitness Smart wristband Oral health Blood Pressure Monitor Otoscope Massager Humidity Thermometer other Smart ElecyronicsTracker/Anti Lost Device Alarm System Electric Charging tool Solar Power Cables|Connectors|PCB|kitsDupont Wire Adapter USB Socket Converter USB Converter Cable DIY Kit HDMI Computers,TV Home Audio ElectrKeyboard Mouse Heatsink Cooling fan Screen/Media player Wireless Receiver Devices TV Box NetworkingAdapters&Antennas Games Accessories Consumer ElectronicsCamera Headset Power Bank Microphone Speaker Radio Smart Switch PIR Sensor Memory Fingerprint Lock Smart Watch Clock Electronic scale Humidifier Steam brush Projector Flashlight other Motorcycles & AccessoriesBicycle Motorcycle other ToysMagic Cube Playing Card Mask Gyro/Hand Spinner RC Cars Other other BatteryLithium battery PCB board lithium/Li-ion battery Battery Case other Sports & OutdoorFishing&Hunting SOS kit Camping light other Other Product View Detail Features: Dual mode PWM pulse number frequency duty cycle adjustable generator module square wave rectangular wave A variety of practical scenes! ! ! 1.PWM signal generator, square wave rectangular wave signal generator 2. Used to generate a square wave rectangular wave signal, which is supplied to a DC motor or a stepper motor driver; 3. Combine the driver to realize dimming, speed regulation, control solenoid valve, etc. However, it is not possible to directly drive loads such as electric lights, motors, and solenoid valves. 1. Highlights: 1.1 Two modes can be selected: PWM mode - frequency (continuous), duty cycle, pulse number adjustable; PULSE mode - positive pulse width time, negative pulse width time, delayed start time, and adjustable number of pulses. 1.2 With start and stop button, can control the output and stop of the signal 1.3 Wide voltage input 3.3-30V, with anti-reverse protection, 5.08mm terminal wiring 2. Technical parameters: 2.1 Working voltage: 3.3~30V, with anti-reverse protection 2.2 Frequency range: 1Hz~150KHz, accuracy about 2% 2.3 duty cycle range: 0-100%, 1% stepping 2.4 number of pulses: 1-9999, or infinite (display ‘----’ stands for infinity) 2.5 delay output time: 0.000s-9999s, the minimum can be set 1ms 2.6 positive and negative pulse width length: 0.000s-9999s, the minimum can be set 1ms 2.7 signal loading capacity: less than 30mA 2.8 Output signal amplitude: amplitude is equal to the supply voltage 2.9 Product size: 60mm*32mm*10mm 2.10 Product Weight: 18g 2.11 Packing: Anti-static bag 3. Module description: 3.1 button operation instructions 3.2 PWM mode (display has "%" for PWM mode) The factory default mode is PWM mode, FREQ+ and FREQ-key set frequency, DUTY+ and DUTY-button set duty cycle; short press STOP button control signal output or stop, stop output is 0, the screen displays “OUT” mark as There is output, otherwise it stops output; the default factory frequency is 1KHZ and the duty cycle is 50%. If you want to switch to PULSE mode, long press the SET button (more than 6 seconds), do not release, you will see the screen change, "%" disappears, it is PULSE mode. 3.3 PULSE mode (No "%" on the right side of the display is PULSE mode) The line above the LCD screen displays the positive pulse width time. The P+ and P- buttons set the parameter. The line below the LCD screen displays the negative pulse width time. The N+ and N- buttons set the parameter. Press the STOP button to control the signal output or stop. When the output is stopped, the output is 0. The screen displays “OUT” for output, otherwise it stops output; the default factory positive pulse width is 0.5 seconds and the negative pulse width is 0.5 seconds. Pulse number and delay time setting - In PULSE mode, press and hold the SET button for 2 seconds and then release, enter the pulse number and delay time setting interface, the screen displays SET, it will be turned off and cleared after entering. ;P+ and P- buttons set the delay time, N+ and N- buttons set the number of pulses, the factory default delay time is 0 seconds, the number of pulses is infinite (display ----); then press SET button 2 In seconds, it will automatically return to the pulse interface, press the STOP button, after the delay setting time, start to issue the set number of pulses. If the number of pulses is sent, it will automatically output 0. If the period is not sent, pressing the STOP button will turn off. The output pulse is turned off and cleared, and the set number of pulses is issued each time it is started. 3.4 Application Operation Examples 3.4.1 PWM output 20KHZ, 60% duty cycle: Select PWM mode, the frequency is set to 20.00, and the duty ratio is set to 060%. 3.4.2 The output is turned on for 0.6 seconds and turned off for 0.2 seconds. Infinite loop: select PULSE mode, the positive pulse width is set to 0.600, the negative pulse width is set to 0.200, the delay time is set to 0.000, and the number of pulses is set to --- -. 3.4.3 Power on or press the start button, delay 5 seconds, then the output is turned on for 0.6 seconds, off 0.2 seconds, infinite loop: select PULSE mode, positive pulse width is set to 0.600, negative pulse width is set to 0.200, delay The time is set to 5.000 and the number of pulses is set to ----. 3.4.4 Power on or press the start button, delay 5 seconds, then output high level 10ms low level 10ms pulse 100: select PULSE mode, positive pulse width is set to 0.010, negative pulse width is set to 0.010, delay The time is set to 5.000 and the number of pulses is set to 0100. 3.4.5 Power-on delay for 10 seconds, then permanently output signal: select PULSE mode, the positive pulse width is set to a number greater than 0, the negative pulse width is set to 0, the delay time is set to 10.00 seconds, and the pulse number is infinite. (----). 3.4.6 Other applications can explore or consult customer service All setup parameters are not lost when they are turned off. (PP2 Power output) Features: High-power PWM dimming speed control module solenoid valve number frequency duty cycle adjustable cycle delay A variety of practical scenes! ! ! 1. LED brightness adjustment, frequency, duty cycle can be adjusted 2. Motor speed adjustment, frequency and duty cycle can be adjusted 3. Drive the solenoid valve to pull and release, automatic cycle, delay output, cycle number (or infinite loop) can be set. 4. Control equipment to turn on and off, do switch fatigue test, voltage sag and other tests to verify the reliability of customer equipment. 5. Delay start load, delay time can be set, after the delay, it will be turned on or intermittently. 1. Highlights: 1.1 can directly drive LED, motor, solenoid valve and other loads 1.2 Two modes can be selected: PWM mode - frequency (continuous), duty cycle, pulse number adjustable; PULSE pulse mode - positive pulse width time, negative pulse width time, power-on delay start time, and number of pulses are adjustable. 1.3 With start and stop button, can control the output and stop of the signal 1.4 Wide voltage input 3.3-30V, 5.08mm terminal wiring 2. Technical parameters: 2.1 Working voltage: 3.3~30V (note that the positive and negative poles should not be reversed, otherwise it may burn out) 2.2 Frequency range: 1Hz~150KHz, the accuracy is about 2%. Motor speed control generally chooses 20KHZ 2.3 duty cycle range: 0-100%, 1% stepping 2.4 number of pulses: 1-9999, or infinite (display ‘----’ stands for infinity) 2.5 delay output time: 0.000s-9999s, the minimum can be set 1ms 2.6 positive and negative pulse width length: 0.000s-9999s, the minimum can be set 1ms 2.7 output load capacity: less than 8A (MOS switch tube) 2.8 Output amplitude: The amplitude is equal to the supply voltage (OUT+ is directly connected to the V+ module) 2.9 Product size: 60mm*32mm*10mm 2.10 Product Weight: 20g 2.11 Packing: Anti-static bag 3. Module description: 3.1 button operation instructions 3.2 PWM mode (display has "%" for PWM mode) The factory default mode is PWM mode, FREQ+ and FREQ-key set frequency, DUTY+ and DUTY-button set duty cycle; short press STOP button control signal output or stop, stop output is 0, the screen displays “OUT” mark as There is output, otherwise it stops output; the default factory frequency is 1KHZ and the duty cycle is 50%. If you want to switch to PULSE mode, long press the SET button (more than 6 seconds), do not release, you will see the screen change, "%" disappears, it is PULSE mode. 3.3 PULSE mode (No "%" on the right side of the display is PULSE mode) The line above the LCD screen displays the positive pulse width time. The P+ and P- buttons set the parameter. The line below the LCD screen displays the negative pulse width time. The N+ and N- buttons set the parameter. Press the STOP button to control the signal output or stop. When the output is stopped, the output is 0. The screen displays “OUT” for output, otherwise it stops output; the default factory positive pulse width is 0.5 seconds and the negative pulse width is 0.5 seconds. Pulse number and delay time setting - In PULSE mode, press and hold the SET button for 2 seconds and then release, enter the pulse number and delay time setting interface, the screen displays SET, it will be turned off and cleared after entering. ;P+ and P- buttons set the delay time, N+ and N- buttons set the number of pulses, the factory default delay time is 0 seconds, the number of pulses is infinite (display ----); then press SET button 2 In seconds, it will automatically return to the pulse interface, press the STOP button, after the delay setting time, start to issue the set number of pulses. If the number of pulses is sent, it will automatically output 0. If the period is not sent, pressing the STOP button will turn off. The output pulse is turned off and cleared, and the set number of pulses is issued each time it is started. 3.4 Application Operation Examples 3.4.1 PWM output 20KHZ, 60% duty cycle: Select PWM mode, the frequency is set to 20.00, and the duty ratio is set to 060%. 3.4.2 The output is turned on for 0.6 seconds and turned off for 0.2 seconds. Infinite loop: select PULSE mode, the positive pulse width is set to 0.600, the negative pulse width is set to 0.200, the delay time is set to 0.000, and the number of pulses is set to --- -. 3.4.3 Power on or press the start button, delay 5 seconds, then the output is turned on for 0.6 seconds, off 0.2 seconds, infinite loop: select PULSE mode, positive pulse width is set to 0.600, negative pulse width is set to 0.200, delay The time is set to 5.000 and the number of pulses is set to ----. 3.4.4 Power on or press the start button, delay 5 seconds, then output high level 10ms low level 10ms pulse 100: select PULSE mode, positive pulse width is set to 0.010, negative pulse width is set to 0.010, delay The time is set to 5.000 and the number of pulses is set to 0100. 3.4.5 Power-on delay for 10 seconds, then permanently output signal: select PULSE mode, the positive pulse width is set to a number greater than 0, the negative pulse width is set to 0, the delay time is set to 10.00 seconds, and the pulse number is infinite. (----). 3.4.6 Other applications can explore or consult customer service All setup parameters are not lost when they are turned off. Feedback Payment Shipment About us Feedback We appreciate positive feedback . we always try our best to service our customers . so if you have ant question ,PLEASE DON’T HESITATE TO TELL US, we are always here to offer help . Payment We prefer PayPal .For purchasing multiple items , please contact us for a combined invoice . generally we would like to receive payment thin 48 hours if . Shipment We provide airmail service with good package . The items will be shipped within the nest 2 business days after we received the payment . when you buy multiple items ,your shipping cost will be combined with discount . SHIPPING TIME (weekends/holidays excluded) Country Name Shipping Time Country Name Shipping Time USA/Canada 10 -15d Spanish/Portugue 10-25d East/South Asia 10 -15d France/West Asia 10-25d United Kingdom 10 -20d Italy 10-30d Australia/New Zealand 10 -15d West Asia/Middle East 15-25d Most Country of West/North Europe 10-20d South America and Africa 15-30d East /Middle Europe/Russia 10-25d About us NEW, GOOD QUALITY, ORIGINAL PACKAGE LARGE STORE AND THE LOWEST PRICE NO-QUESTION-REFUND, FOR LARGE QUANTITY ,OFFER BETTER PRICE,ORIGINAL PACKING(TAPE REEL/TUBE/TRAY We specialize in electronic components . ICs, Capacitors, Diodes, Resistors, LEDs, Transistors, and so on. Especially in Hard To Find Parts . we only sell NEW , ORIGINAL parts . please buy with confidence .We offer NO-QUESTION-REFUND go to my store

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Frequency Range	1Hz-150KHz
MPN	Does not apply
Working voltage	3.3-30V
UPC	Does not apply
duty cycle range	0-100%
EAN	Does not apply
number of pulses	1-9999
