Dual SPDT Power Relay Module, for Arduino Project Applications. sku731701a, US $600 – Picture 0
Dual SPDT Power Relay Module, for Arduino Project Applications. sku731701a, US $600 – Picture 0

Dual Spdt Power Relay Module, For Arduino Project Applications. Sku731701a

US $600

  • Hong Kong, Hong Kong
  • Jan 29th
Open on mobile:
QR code
Description Dual SPDT Power Relay Module, for Arduino Project Applications. Can be directly plugged into Arudino UNO R3 or MEGA 2560 R3 board, avoiding some painful wires connection. OMRON G5LA-14 12V Power Relays, LED indicator for each relay action. Screw terminal block connect relay switch and external power supply. Two tact switches (momentary) you can use them flexibly via Arduino firmware. On board jumper option, you can choose power supply from Arduino VIN or terminal block. Operating Voltage / Current (max.): 9 ~ 18 VDC / 80mA. Relay max. switching voltage: 24 VDC. Relay max. switching current: 10A(NO), 5A(NC). PCB dimensions: 49mm x 53mm. The package no paper specifications, please download these files. Schematic: http://www.audiowind.com/Schematic/D-248Schematic.pdf Reference source code: http://www.audiowind.com/SourceCode/D-248ArduinoSourceCode.rar Note: the item not include Arduino UNO or MEGA 2560 module. For Arduino UNO R3 Mount Picture For Arduino MEGA 2560 R3 Mount Picture sku731701a Your partner for managing your online business
