Dvr - 4 Channel Low Cost Dvr 2 Cif - 500gb Hd

US $555.85

Boca Raton, Florida, United States
Jan 30th

Open on mobile:
QR code

Overview 4ch video inputs All channel@ 2CIF realtime recording HDMI, VGA output up to 1080p 4ch sync realtime playback 1 SATA, 2 USB, 1 RJ45(100M) Includes 500 GB Hard Drive Includes Mouse and Remote Control Key Features 4 ch DVD Quality (7.5fps) or 2CIF (30fps) in H.264 4 cameras with 1080p realtime preview Free DNS Server works with all internet providers Backs up to the "Cloud" for offsite video storage 1x HDMI / 1x VGA / 2x USB 2.0 / 1x RJ-45 Embedded Linux Processor H.264 / G.711 dual-stream video compression 4 rectangle privacy mask zones per camera 4 BNC Video Inputs - NTSC ( 525Line, 60f/s) Main Stream Record: D1(1~6/7fps) 2CIF(1~25/30fps)/2ch@D1+2ch@CIF(1~25/30fps) Extra Stream Record: QCIF(1~25/30fps) Support 1 SATA HDDs up to 4TB, 2 USB2.0 Recording Modes: Manual, Schedule (Continuous, Motion Detection, Alarm), Stop All channel synchronous realtime playback, GRID interface & smart search Multiple network monitoring: Web viewer, CMS & Smart Phone App On Screen Display of Camera Title, Time, Video Loss, Camera Lock, Motion Detection, Recording Smart Phone Compatible: iPhone, iPad, Android, Windows Phone System Main Processor Embedded processor Operating System Embedded LINUX Video Input 4 channel, BNC Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s) Display Interface 1 HDMI,1 VGA, Resolution 1920x1080, 1280x1024, 1280x720, 1024x768 Display Split 1/4 Privacy Masking 4 rectangular zones (each camera) OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording Recording Video/Audio Compression H.264 / G.711 Resolution D1(704x576/704x480)/2CIF(704x288/704x240)/CIF(352x288/352x240)/ QCIF(176x144/176x120) Record Rate Main Stream: D1(1~6/7fps)2CIF(1~25/30fps)/2ch@D1+2ch@CIF(1~25/30fps) Extra Stream CIF(1~6/7fps)/ QCIF(1~25/30ps) Bit Rate 48~3072Kb/s Record Mode Manual, Schedule(Regular(Continuous), MD), Stop Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec Video Detection Trigger Events Recording, Tour, Video Push, Email, FTP, Buzzer & Screen tips Video Detection Motion Detection, MD Zones: 396(22x18), Video Loss & Camera Blank Playback & Backup Sync Playback 1/4 Search Mode Time/Date, MD & Exact search (accurate to second) Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom Backup Mode USB Device / Network Network Ethernet RJ-45 port (10/100M) Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter Max. User Access 20 users Smart Phone iPhone, iPad, Android, Windows Phone Storage Internal HDD 1 SATA port, up to 4TB Auxiliary Interface USB Interface 2 ports (2 Rear), USB2.0 General Power Supply DC12V/2A Power Consumption 10W(without HDD) Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa Dimension(WxDxH) 205mmx205mm Weight 0.5KG

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	DVR (Digital Video Recorder)
Hard Drive Capacity	500GB
Number of Channels	4
Features	Audio Recording, DVD-RW Backup, Mobile Phone Access, Real-Time Recording, Time Lapse
Brand	CLEARVIEW
Country/Region of Manufacture	United States
Model	FALCON-04E
