Dwyer 2010-c Series Magnehelic Differential Pressure Gauges

US $83

Livingston, New Jersey, United States
Jun 11th

Open on mobile:
QR code

Dwyer 2010-C Series Offers Features: Bezel provides flange for flush mounting in panel Clear plastic face is highly resistant to breakage and provides undistorted viewing of pointer and scale Precision litho-printed scale is accurate and easy to read. Red tipped pointer of heat treated aluminum tubing is easy to see. It is rigidly mounted on the helix shaft. Pointer stops of molded rubber prevent pointer over-travel without damage. "Wishbone" assembly provides mounting for helix, helix bearings and pointer shaft. Jeweled bearings are shock-resistant mounted; provide virtually friction-free motion for helix. Motion damped with high viscosity silicone fluid. Zero adjustment screw is conveniently located in the plastic cover, and is accessible without removing the cover. O-ring seal provides pressure tightness. Helix is precision made from an alloy of high magnetic permeability. Mounted in jeweled bearings, it turns freely, following the magnetic field to move the pointer across the scale. Calibrated range spring is flat spring steel. Small amplitude of motion assures consistency and long life. It reacts to pressure on diaphragm. Live length adjustable for calibration. Silicone rubber diaphragm with integrally molded O-ring is supported by front and rear plates. It is locked and sealed in position with a sealing plate and retaining ring. Diaphragm motion is restricted to prevent damage due to overpressures. Die cast aluminum case is precision made and iridite-dipped to withstand 168 hour salt spray corrosion test. Exterior finished in baked dark gray hammerloid. One case size is used for all standard pressure options, and for both surface and flush mounting. Blowout plug is comprised of a rubber plug on the rear which functions as a relief valve by unseating and venting the gage interior when over pressure reaches approximately 25 psig (1.7 bar). To provide a free path for pressure relief, there are four spacer pads which maintain 0.023" clearance when gage is surface mounted. Do not obstruct the gap created by these pads. The blowout plug is not used on models above 180" of water pressure, medium or high pressure models, or on gages which require an elastomer other than silicone for the diaphragm. The blowout plug should not be used as a system overpressure control. High supply pressures may still cause the gage to fail due to over pressurization, resulting in property damage or serious injury. Good engineering practices should be utilized to prevent your system from exceeding the ratings or any component. O-ring seal for cover assures pressure integrity of case. Samarium Cobalt magnet mounted at one end of range spring rotates helix without mechanical linkages. Applications Filter Monitoring Air Velocity with Dwyer Pitot Tube Blower Vacuum Monitoring Fan Pressure Indication Duct, Room or Building Pressures Clean Room Positive Pressure Indication Frequently Asked Questions Q: How long will it take to receive my order? A: We ship your order as quickly as possible. Economy orders should be received in 5-8 business days. Standard shipping will arrive in 3-5 business days. Q: Will you accept payment methods other than PayPal? A: At this time we can only accept payment via PayPal. PayPal is fast and secure and it protects both the buyer and seller from many types of internet scams. Q: I left you positive feedback, when are you going to leave me feedback? A: Our system automatically leaves positive feedback for each and every when your order ships. Thanks for your order! Q: After I placed my order I decided I don't need the book. What can I do? A: We will refund any purchase within 30 days once we receive the item back in the same condition in which we shipped it. We reserve the right to charge a 20% restocking fee for items that are returned for reasons other than an error on our part. Send returns to: 275 East Northfield Road Livingston, NJ 07039-4811 Once we receive the item we will authorize a refund through PayPal for the amount of the item less the shipping fee.
