Dwyer Mercoid Da-7031-153-5 Pressure Switch 2 - 60 Psi

US $79.99

Millstone Township, New Jersey, United States
Jul 20th

Open on mobile:
QR code

Dwyer Mercoid DA-7031-153-5 Pressure Switch 2 - 60 PSI Mercoid DA-7031-153-5 pressure switch, brass Bourdon tube, range 2-60 psig, 13.5 psig min. deadband. Wetted Materials: Brass, 403 SS, or 316 SS. Temperature Limit: 180°F (82°C). Pressure Limit: Maximum pressure of the operating range. Enclosure Rating: General purpose, weatherproof or explosion-proof. Repeatability: ±1% of full operating range, ±1.5% on DS-7300 models. Switch Type: SPST mercury switch, SPDT mercury switch, SPDT snap switch, or SPDT hermetically sealed snap switch. Other circuit types available. Electrical Rating: See Catalog page. Electrical Connections: Screw terminal. Conduit Connection: General purpose: 1/2" hole for conduit hub. Weatherproof: 1/2" conduit hub. Explosion-proof: 3/4" female NPT. Process Connection: General purpose and weatherproof: 1/4" male NPT; 1/2" male NPT on range 15S and 16S. Explosion-proof: 1/2" male NPT and 1/4" female NPT. Mounting Orientation: Vertical. Set Point Adjustment: Thumbscrew. Weight: General purpose: 4 lb (1.8 kg). Weatherproof: 6 lb (2.7 kg). Explosion-proof: 8 lb (3.5 kg). Deadband: See Catalog page. Agency Approvals: CE, UL, CSA, FM. (Mercury switch units are not CE approved). (Consult factory for which models have what approvals.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Mercoid
MPN	DA-7031-153-5
UPC	Does not apply
