Dwyer Series DX Differential Pressure Switch DXW-11-153-1, US $700 – Picture 0
Dwyer Series DX Differential Pressure Switch DXW-11-153-1, US $700 – Picture 0

Dwyer Series Dx Differential Pressure Switch Dxw-11-153-1

US $700

  • Gardner, Kansas, United States
  • Jun 4th
Open on mobile:
QR code
Series DX Wet/Wet Differential Pressure Switch, brass and fluoroelastomer wetted materials, NEMA 4X, 1/4" NPT connections, SPDT, range 2.5 to 10 psi. NEMA 4X Enclosure, Low Differential Set Points The Series DX is a differential pressure switch that makes a contact output based on the differential between two pressure sources. Wetted materials of brass and flouroelastomer are suitable for use with most gases and water based solutions. Unit features a high static pressure rating of 200 psig (13.8 bar) for higher static pressure applications. Series DX incorporates an externally adjustable set point, integral mounting flange and a removable electrical terminal block for quick and easy installation. The DX uses opposing diaphragms to sense the high and low pressure with a pivot mechanism that transfers the difference of the two pressures to the SPDT switch. Product Applications Indicating filter differential pressure. For example initiating water filter backwash as the filter becomes clogged on increasing differential pressure. Proof of flow indicator monitoring differential pressure from a sensing device. For example sensing the pressure across an orifice plate to prove water flow. Proving flow through a pump by sensing the pressure across the pump to make sure the pump does not run dry. Proving flow through a chiller. Often called evaporator water pressure drop. Proving flow through a heat pump or AC unit. Often called a condenser water lock-out switch. Approvals CE Approval UL Approval_CA UL Approval_US BRAND NEW , MISSING ORIGINAL PACKAGE
