E49 Transformer Cores, Power Ferrite, 500mT Bsat (x2) EE49, US $5.60 – Picture 0
E49 Transformer Cores, Power Ferrite, 500mT Bsat (x2) EE49, US $5.60 – Picture 0

E49 Transformer Cores, Power Ferrite, 500mt Bsat (x2) Ee49

US $5.60

  • Lewis, New York, United States
  • Jan 29th
Open on mobile:
QR code
******    E-49  Ferrite  Cores        Qty: 1 complete transformer (2 halves)     Permeability = 3000,  B(sat) = 500 mT Low core loss ferrite NOS Arnold Engineering     Dimensions: 49mm x 23mm x 11.3mm   each half. Magnetic Path length:  10.295 cm Eff. Core Area:  1.74 cm ^2 Eff. Core Volume:  17.86 cm ^3 Power Handling capability index (WaAe)  4.75 cm^4 iNDUCTANCE iNDEX (AL):  5840 nH/N^2 Example schematic of 1000W Switching power supply  Web site showing how to build a 1KW SMPS Note: Depending on construction, an E49 core can produce 1-1.2KW max power.  Maximizing factors will include a full bridge topology, 100KHz+ operating frequency, and use of triple-insulated winding wire to optimize transformer performance. Material: ASTM P5025 ( TSF50 ) power ferrite. Material Properties:     Manufacturer's QC certification sheet for this lot adds the following information: Al value: 4966  nH / T^2   +/- 25%,  average of 16 samples from the lot, taken with an Agilent 4275A LCR Analyzer, Turn count = 20, Freq = 20KHz     IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally.
