E55 Large Volume Low Profile Transformer Core Low Loss, Power Ferrite X4-:

US $30

  • Valley Stream, New York, United States
  • Jan 29th
Open on mobile:
QR code
   E-55  Ferrite E-Cores LARGE-VOLUME LOW PROFILE FORM FACTOR   E 55-28-31             Qty: 4 core halves, 2 complete transformer   Permeability = 3000,  B(sat) = 500 mT Low core loss ferrite 50mW/cc NOS Arnold Engineering   Dimensions: 51mm x 28mm x 31mm   each half. Magnetic Path length:  12.335 cm Eff. Core Area:  5.291 cm ^2 Eff. Core Volume:  65.27 cm ^3 Power Handling capability index (WaAe)  21.040 cm^4 INDUCTANCE iNDEX (AL):  14910 nH/N^2 Material: ASTM P5025 ( TSF50 ALL ) power ferrite. Material Properties:   Manufacturer's QC certification sheet for this lot adds the following information: Al value: 14902  nH / T^2   +/- 25%,  average of 10 samples from the lot, taken with an Agilent 4275A LCR Analyzer, Turn count = 1, Freq = 100KHz   Example schematic of 1000W Switching power supply  Web site showing how to build a 1KW SMPS       IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally. supreme supremewidgets supremeauctiononlinesoftware.widgets.EbayGalleryZ.swf supremewidgets supremeauctiononlinesoftware.widgets.GalleryCat.swf supremewidgets supremeauctiononlinesoftware.widgets.FeedbackWidgetBasic.swf
