Ec-400 Little Giant Mini Condensate Pump 553450

US $250

Charleston, South Carolina, United States
Jun 19th

Open on mobile:
QR code

Product Overview: The EC-400 is a complete pumping system designed to remove condensation from wall mounted, ceiling and coil split-system air conditioning equipment when gravity drainage is not possible. Compact design allows installation in most split-systems. Components can be placed into the air handler or the pump can be placed up to 3' above the air handler in the ceiling void or inside trunking conduit. A three position symmetrical float sensing system assures reliable ON, OFF and OVERFLOW DETECTION functions. Product Features: For application with intermittent operation — maximum 50% duty cycle Compact two-piece design allows flexible installation for most mini-split air conditioning units up to 25,000 BTU/hr Quiet operation Pump is self-priming and can be located up to 3' above reservoir Includes: Suction tubing (3' x 5/32" ID), Vent tubing (8" x 5/32" ID), Drain tubing (3" x 1/2" ID), Tubing adapter (5/32" x 1/4"), and Safety Switch Condensate produced in application must be no more than 1/2 the pump's flow rate for any given head Product Specifications: Flow - 2.5 GPH @ 1' of head Electrical - 115 V, 60 Hz, 0.24 Amps, 19 Watts 35' Shut-off 3' Suction lift Weight - 1.17 lbs New in box Ships to 48 continental USA only Pet free and smoke free home Please review photos and ask questions before purchasing. * note: I will be out of town from 6/23/16-6/26/26 and 7/1/16-7/18/16 and will be unable to ship during these dates. *
