Elane Load Cell Transmitter 4-20ma - New

US $180

Xiamen, China
Jan 29th

Open on mobile:
QR code

Load Cell Transmitter 4-20mA FREE 4GB USB bracelet with every order amount of over US$100.00 Elane Load Cells and accessories are economical and highly accurate. For over 25 years, we have manufactured load cells and accessories for our scales and supplied large quantities of standard and custom made load cells internationally for other businesses and manufacturers. Load Cells also available in our Ebay store. Please see our Ebay store for more details and picture Load Cells. Easy to use quality analog load cell amplifier board only $28.00 including shipping also available in our Ebay store. Please see our Ebay store for more details and a picture of the board. Calibration Weight Set also available in our Ebay store. Please see our Ebay store for more details and a picture of the Calibration Weight Set. 25lb Load Cell Kit only US$48.00 including shipping also available in our Ebay store. Please see our Ebay store for more details and a picture of the kit. BUY NOW --- each auction item on our listing has a corresponding store item if you want to BUY the PRODUCT NOW. Please also visit our store for related items. Our Store also has many other load cells to choose from Specifications Operating Environment: Temperature: 0-50 degrees. Humidity: 30 to 80 percent, non-condensing. Power Supply Requirements: Operating voltage: DC12v~24V 100mA MAX. Current Output Range: From 4mA to 20mA. Potentiometer Function Descriptions: W1: Load Cell’s zero adjustable electronic potential. W2: Load Cell’s amplification gain adjustable electronic potential. W3: Initial output current zero adjustable electronic potential. Calibration Instructions: Looking at the transmitter, you can find the electronic potential and the terminal tabs. Connect the Transducer/Load Cell to Input, and connect the system of measurement to Output, then the power supply to turn on. 1. Adjust W1 first, so as to the voltage between V and GND is 0.5V (check with voltage meter). 2. In IOUT and LOAD (250 ohm) series between a current meter, Put nothing on load cell, then adjust w3, obtaining the Initial current output with 4mA. 3. Put full load on load cell, then adjust w2, obtain the full scale output current 20mA. 4. Remove the weight on the load cell, if the output is not the initial output, repeat the step 1 and 3 until the initial output is 4mA and the full scale output is 20mA. Diagram User Manual http://www.elane.net/UserManuals/Load Cell Transmitter 4-20mA Manual.pdf FREE 4GB USB bracelet with every order amount of over US$100.00 Can you trust scale_bargains? Bid on this item with confidence - see our feedback. YOU CAN BUY WITH CONFIDENCE! We are a verified eBay seller and verified paypal member. We have over 4800 positive feedback - growing daily - our prices are right and our service aims to please our buyer. Our products are outstanding and we service our products for many years to come. Support Our email support is located in a different time Zone (Asia) - but we answer every email received from Monday to Friday GMT+6 - so please do not hesitate to ask questions or request a datasheet. Please ask all questions before placing a bid - all sales are final. My policy is not to make side deals during the course of the auction, so please do not ask! These items are for experimental use by buyers with experience in electronics and load cells. The products are 100% tested functional upon shipment. This kit product which requires interaction of the buyer for final configuration does not have any warranty. Shipping Shipment by Registered Post but we can also ship using services like DHL, TNT, or UPS to have traceable shipment.. Pick-ups from stock not possible - items must be shipped. Payment We prefer payments.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Elane
Country of Manufacture	China
