Elco Corp M55074/1 Connector, Plug, Electrical Nsn 5935-00-577-8846

US $540

Westerville, Ohio, United States
Jun 20th

Open on mobile:
QR code

Elco Corp M55074/1 Receptacle Electrical NSN 5935-00-577-8846 Location:5B5 Technical Definition Connector, Plug, Electrical, also referenced with federal logistics item name code 01938 - An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or printed wiring board and is not designed to be mounted on a bulkhead, chasses, panel, printed wiring board, or the like. excludes jack, telephone; jack, tip; plug, telephone; plug tip; insert, electrical connector; connector body (as modified); and socket, plug-in, electronic components. see also lead assembly, electrical; wiring harness (as modified); and cable assembly (as modified). for items without inserts, see shell, electrical connector.Technical Characteristics Cable Entrance Diameter (AFQJ): 0.590 inches maximum Connector Cable Strain Relief Method (AFRW): Cord grip Connector Locking Method (AFRV): Cam and lever Contact Material Document And Classification (CSGF): Qq-c-530 fed spec single material response single mating end single contact grouping Contact Material (CQTZ): Copper alloy single mating end single contact grouping Contact Removability (AFQZ): Nonremovable single mating end single contact grouping Contact Surface Treatment Document And Classification (CRBJ): Mil-g-45204,ty 2,grade d,cl 2 mil spec single treatment response single mating end single contact grouping Contact Surface Treatment (CQYH): Gold single mating end single contact grouping Environmental Protection (ADZC): Watertight Mating End Quantity (AFQW): 1 Overall Diameter (ADAV): 2.750 inches nominal Included Contact Quantity (CXCG): 52 single mating end single contact grouping Included Contact Type (CXCL): Hermaphrodite single mating end single contact grouping Insert Material Document And Classification (CTKL): Mil-m-14,ty sdg-f mil spec single material response single mating end Insert Material (CQZG): Plastic diallyl phthalate single mating end Shell Material Document And Classification (CTHH): Qq-a-591 fed spec single material response Shell Material (CSPT): Aluminum alloy 380.0 Shell Surface Treatment (CSWM): Anodize Overall Length (ABHP): 13.500 inches maximum Precious Material And Location (PMLC): Contact surfaces gold Precious Material And Weight (PMWT): 0.052 gold grains, troy Precious Material (PRMT): Gold Specification/standard Data (ZZZK): 81349-mil-c-55074/1 government specification Terminal Location (CQTM): Back single mating end single contact grouping Terminal Type (CSCF): Tab, solder lug single mating end single contact grouping Test Data Document (TEST): 81349-mil-c-55074 specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.). National Stock Number (NSN) 5935-00-577-8846
