Elecfreaks Iot:bit For Micro:bit

US $16.90

Swanton, Vermont, United States
Jul 29th

Open on mobile:
QR code

Description ElecFreaks iot:bit for micro:bit Designed for BBC micro:bit Programmable Board (not included) Features an integrated ESP12F WiFi, RTC and passive buzzer module Offers most IO ports extended by GVS Lets you directly plug in: OLED, BME280, and IIC Includes an integrated buzzer and earphone jack The ElecFreaks iot:bit for micro:bit is an expansion board based on IoT for micro:bit. It uses ESP8266 as WIFI expansion board and serial port to communicate with micro:bit. It also has extended all available IO port of the micro:bit which is controlled by GVS and you can extend various 3V E-blocks as LED, photosensitive and servo by using it. At the same time, the IOT:bit with an on-board buzzer for outside sound and an on-board RTC clock for timing without power supply. Start creating your own IoT device by makecode! Specifications DC supply: USB-5 V Maximum power current: 800 mA Operation temperature: -25~80 Wifi module: ESP8266, ESP12F Buzzer: Passive buzzer RTC timing: DS1307 RTC RTC timing battery: CR1220 button cell, Equipped by yourself Lead out: Not all Port lead: Serial port can map the IO port Coding I2C port lead: 19, 20 pin, Only for I2C pin SPI port lead: 14, 15 pin, for common IO Net weight: 30 g What's Included 1 x ElecFreaks iot:bit for micro:bit Dimensions 71 x 63 mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ELECFreaks
Type	ELECFreaks
MPN	EF03426
UPC	Does not apply
