Electric Precision 4" Width Rolling Press with Dual Micrometer - MSK-HRP-MR100A, US $2,850.00 – Picture 0
Electric Precision 4" Width Rolling Press with Dual Micrometer - MSK-HRP-MR100A, US $2,850.00 – Picture 0

Electric Precision 4" Width Rolling Press With Dual Micrometer - Msk-hrp-mr100a

US $2,850.00

  • zhengzhou,henan, China
  • Jan 30th
Open on mobile:
QR code
Electric Precision 4" Width Rolling Press with Dual Micrometer - MSK-HRP-MR100A MSK-HPR-MR100A (upgrade from EQ-MR100A) is a CE Certified compact precision electric rolling press. It has dual rollers of 100 mm dia. x 100mm width and dual grade micrometer. It is an ideal rolling press for adjusting thickness and increasing active material density of the electrode in Li-Ion batteries research after coating and drying. SPECIFICATIONS: Working Voltage 110V / 220V AC single phase selectable 220V AC Power plug is not included.  Max. Power Consumption 500W Total Structure Heavy duty steel frame, gears and handle 100 mm Dia. x 100mm width Rollers made from hardened tool steel (RC > 62) with Cr electroplated coating Dual micrometer for accurate thickness adjustment in the range 0 - 1.8 mm Maximum Roller Dimensions: 100mm(Dia.) x 100mm(W) Material: Made from hardened tool steel (RC > 62) with Cr electroplated coating Power: Driven by 0.5 HP high touqe gear AC Motor Constant Rolling Speed: 65 mm / second Product Dimensions 381 mm(L) x 241.3mm(W) x 355.6mm(H) (15" x 9.5" x 14")  Compliance CE Certified Warranty One year limited manufacture warranty with lifetime support Rusting and damage due to improper storage condition or maintenance is not covered by warranty Application Notes The MSK-MR-100A roller is specially designed for battery R&D in terms of its advantages as affordable, compact and precise. Please strictly follow the instructions during operation Must use acetone to clean and dry rollers' surfaces after each use to avoid rusting Apply antirough if machine were to be unused for a long period of time Never roll materials with hardness > 50HRC The minimum thickness of the rolled sheet should depend on the physical property of the materials. Here are some results from our test: Electrode Size Original thickness Finished thickness LiFePO4 double sides 50mm Width x 260mm Length    0.205mm 0.09mm LiMn2O4 double sides 50mm Width x 260mm Length 0.205mm 0.09mm Copper foil + graphite (single side) 75mm Width x 240mm Length 0.09mm 0.04mm Sample testing is available upon customer's request Net Weight 55 kg (180 lbs)
