Electrical Receptacle Connector - P/n Ms3120e14-15s

US $35

Hurricane, Utah, United States
May 24th

Open on mobile:
QR code

ELECTRICAL RECEPTACLE CONNECTOR P/N # MS3120E14-15S NSN # 5935-00-947-9349 Military Spec Brand New - Never been Used AAQL BODY STYLE 5G STRAIGHT SHAPE, EXTERNAL COUPLING W/BACKSHELL ABHP OVERALL LENGTH 1.552 INCHES MAXIMUM ABKW OVERALL HEIGHT 1.141 INCHES MAXIMUM ABMK OVERALL WIDTH 1.141 INCHES MAXIMUM AEBW CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO HEIGHT 0.906 INCHES NOMINAL AEHA DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY WIDTH 0.906 INCHES NOMINAL AFQK DISTANCE FROM MOUNTING SHOULDER TO FRONT FACE 0.431 INCHES MINIMUM AND 0.462 INCHES MAXIMUM AEBV UNTHREADED MOUNTING HOLE DIAMETER 0.120 INCHES NOMINAL AFRV CONNECTOR LOCKING METHOD BAYONET PIN AFRT SHELL TYPE SOLID CSPT SHELL MATERIAL ALUMINUM ALLOY CTHH SHELL MATERIAL DOCUMENT AND CLASSIFICATION QQ-A-591 FED SPEC SINGLE MATERIAL RESPONSE CSWM SHELL SURFACE TREATMENT CADMIUM CTBC SHELL SURFACE TREATMENT DOCUMENT AND CLASSIFICATION QQ-P-416, TY 2, CL 3 FED SPEC SINGLE TREATMENT RESPONSE AFRN POLARIZATION METHOD KEYWAY OR MULTIPLE KEYWAY AFRP INSERT POSITION IN DEG 0.0 AFQW MATING END QUANTITY 1 AFQX CONTACT POSITION ARRANGEMENT STYLE ARAB 14-15 SINGLE MATING END CXCG INCLUDED CONTACT QUANTITY 1 SINGLE MATING END 1ST CONTACT GROUPING 14 SINGLE MATING END 2ND CONTACT GROUPING AFQZ CONTACT REMOVABILITY REMOVABLE SINGLE MATING END ALL CONTACT GROUPINGS CXCL INCLUDED CONTACT TYPE ROUND SOCKET SINGLE MATING END ALL CONTACT GROUPINGS AFRD CONTACT MAXIMUM AC VOLTAGE RATING IN VOLTS 600.0 SINGLE MATING END ALL CONTACT GROUPINGS CQYH CONTACT SURFACE TREATMENT GOLD AND NICKEL SINGLE MATING END ALL CONTACT GROUPINGS CSCF TERMINAL TYPE CRIMP SINGLE MATING END ALL CONTACT GROUPINGS CQTM TERMINAL LOCATION BACK SINGLE MATING END ALL CONTACT GROUPINGS ADZC ENVIRONMENTAL PROTECTION MOISTURE RESISTANT AND SALT WATER RESISTANT AND VIBRATION RESISTANT TEST TEST DATA DOCUMENT 81349-MIL-C-26482 SPECIFICATION ZZZK SPECIFICATION/STANDARD DATA 81349-MIL-C-26482 GOVERNMENT SPECIFICATION PRMT III PRECIOUS MATERIAL GOLD PMWT III PRECIOUS MATERIAL AND WEIGHT 0.015 GOLD GRAINS, TROY PMLC III PRECIOUS MATERIAL AND LOCATION CONTACT SURFACES GOLD SR-1 MANUFACTURERS CODE 81349 SR-1 NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MIL-C-26482 SR-1 MANUFACTURERS CODE 96906 SR-1 DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MS3120E14-15S Subject to prior sale! For more information, or to contact us, please feel free to visit our ME page. 30 day Right of Return if not satisfied. Thanks for looking!!! Please visit our store for more great items! 2273 - APC3-5
