Electro Pneumatic Transducer Ep-313-020

US $180.00

  • Omaha, Nebraska, United States
  • Feb 25th
Open on mobile:
QR code
Electropneumatic Transducer Model EP-311/313 ..0-10 VDC input • Universal 24 VAC/VDC supply voltage • Short circuit and reverse polarity protected inputs and outputs • Auto/manual switch with separate increase/decrease push-buttons (EP-313) • Precision pressure gauge for branch line indication • Non-interactive zero and span trimmers • Smallest size in the industry SPECIFICATIONS: Accuracy*: ±1% FS Maximum Supply Pressure: 40 psig Pressure Differential: (Supply to Branch) 0.1 psig Supply Voltage: 18-28 VAC/VDC Supply Current: 150 mA Enclosure: 18 Ga C.R. Steel Chassis Finish: Baked on enamel-PMS2GR88B Compensated Temp Range: 25°F-150°F (4°C-65°C) *Includes non-linearity, hysteresis and non-repeatability ORDERING INFORMATION: EPManual Override Range 311 (without) 313 (with) 315 (3-15 psig) 020 (0-20 psig) Example: EP-313-020: With manual override and 0-20 psig range. CONFORMANCE & TESTING: RoHS Compliant EMC Testing: BS EN 55022:1998, BS EN 55024:1998, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-11 T.C. Error: ±0.025%/°F (.03%/°C) Media Compatibility: Clean dry air or any inert gas Port Connection: 1/4" OD poly tubing Environmental: 10-90% RH Non-Condensing Termination: Screw terminal block Wire Size: 12 Ga max. Input Impedance: 301 Ohms (4-20 mA) 10K Ohms (0-5/0-10 VDC) Weight: 1.0 lbs. (.45 kg)
