Element14 Lcd8000-70t-ex1 7" Lcd Module + Conversion Board, Riot / Xplained

US $120

  • Theodore, Alabama, United States
  • Oct 24th
This is like new and was only used 2 or 3 times at most. We just don't need it. It works perfectly and has no issues whatsoever. Comes with everything as pictured. PRODUCT OVERVIEW The LCD8000-70T-EX1 is a 7 inch TFT LCD module with a 16bit RGB parallel conversion board. The conversion board integrates a TSC2046 chip for touch function and a 3.3V regulation chip with capability to implement I2C control and PWM backlight control. It supports 16bit driving modes for LCD displays as well as connecting SPI 4 wire resistive touch screen. To connect the LCD module with RIoTboard, it needs the help of LCD-Ex expansion board. 7" TFT LCD display 4 Wire resistive touchscreen 800 x 480 resolution Five User switches Two user defined LED's 16bit display mode GPIO expansion The blue stripe at the end of 50 pin FPC cable should be facing upward when connecting the LCD module to LCD-Ex expansion board. LCD8000-70T-EX1 do not support hot plugging.
